The bottom heating element in the large oven on my thermador stopped heating, the upper heating element works on bake setting and on broil setting and all else is working properly. Could the ( relay, oven hot wire ) be the cause or can it be something else, thank you
your part # is AP2832020
It is possible that the relay hot wire 414589 could have failed but you would also want to check to make sure that the issue is not with the element itself. You could turn the oven on and check to see if there is 240 vac coming to the element and if not then the relay or board would be the issue. If there is power then the heating element would be the issue.
