Frigidaire 316207522 Oven Control Board

Total
$0.00

Part Number:	AP3672811
MFG Part Number:	316207522
Made by:	Frigidaire

Our Price
$165.28
Regularly	You Save
~~$198.34~~	$33.06

Most Interesting

Marty for Model Number AP3672811

Answer Hello Marty. Disconnect the power. You will remove the back panel off the control panel. Then access the board 316207522 and remove the screws securing the board to the panel. Next install the overlay onto the new board and install the wires from the old board to the proper location on the new board. Install the new board into the unit.

Was this helpful?

Periodically the stove will lose power when there has been no power interruption in the house. Sometimes the the power will be off for a minute or so, then the clock will start flashing. If the elements on the stovetop are in use they will stay on, but the oven stops heating. After a short period of time the unit appears to reset all by its self. The power supply (voltage to receptacle), cord, and terminal block are all in excellent condition. Do you advise replacing circuit board/timer on range? Thanks, Ron

Ron R. for Model Number FEF366ASF

Answer Hello Ron. If all wiring and power supply is good, then you will need to order and replace the control on the unit.

Was this helpful?

My oven element blew apart when taking out the element did not unplug causing a short or power surge. Got new element and replaced it now the oven nor the broiler does not work. The top burners all work and the clock. Do I need to replace theclock unit was that shorted out.

Margie L for Model Number fefl74asa

Answer Hello Margie, You will want to do a voltage check from bake to L1 and broil to L1 on the control board to determine if it is bad. If there is not 240vac then the clock is bad and needs to be replaced. You can test this with a multi-meter TJMA-DMT3. Here is a link on how to use a multi-meter. http://forum.appliancepartspros.com/oven-repair-including-ranges-cooktops/4810-how-check-continuity-ohmmeter.html

Was this helpful?

Latest Questions

My Frigidaire electric range quit working all together. When you try to turn on the cook top you hear a buzzing noise from the clock area. The oven will not turn on at all. Should I replace the EOC?

John for Model Number FEF366ASE

Answer Hello John. Make sure there is 240 volts coming to the unit. IUf so, and the buzzing is from the clock, replace the clock 316207522.

Was this helpful?

Periodically the stove will lose power when there has been no power interruption in the house. Sometimes the the power will be off for a minute or so, then the clock will start flashing. If a a burner or oven is being used, they will go off also. The oven will have to be reset. You also hear a buzzing/arching sound when this occurs. I think I need to replace the clock/timer electronic control, but would like your opinion before I spend over $165.00. Thank you.

WRNGWAE1 for Model Number Kenmore Model #790.95301100

Answer Hello Wrngwae1, Before you replace anything you should check the electrical connections where the "pigtail" (range cord) connects to the terminal block. This is where most problems with a complaint of both the surface and the bake compartment originate. If it is good, check the plug for burned spots on the prongs. If there is a burned spot, you can sand the burn off but the receptacle will require replacement to prevent a fire hazard. Let us know if we can assist you further as I'm confident you will locate the issue. Anytime there is an audible sizzle, the problem can be seen and testing isn't necessary.

Was this helpful?

I got this stove at a yardsale. Stove looks good. I hooked it up. One of the big burners does not work,Front right. And the display does not work. So I can not get the oven to work. I took the back off and all the wires looked ok. Its a Kenmore stove but the parts comming up on this site are for Frigidaire. After reading several questions and answers I think its the contronl panel. But how do you know for sure ? At $160 bucks I want to know for sure. Is there a way to reset the unit ? Or replace a fuse or something? That one big burner thats not working could it be because of the display does not work ? Who has the best prices on parts?

BROKE1 for Model Number 790.95302102

Answer Broke1, There is no "reset" button or fuse to reset or replace. You can check for 120 VAC across the black and white wires going into the clock connector. If you have the voltage, you'll need a new ERC/Clock 316207522 . As for the burner not operating, and as long as you're in the control panel area for the clock. Check the burner infinite switch 316436000 foa closed circuits between the L1 and H1 terminals and the L2 and H2 terminals on the switch,with the switch knob turned on.No closed circuit would indicate a faulty switch.Here's some meter usage information if you need it [http://forum.appliancepartspros.com/oven-repair-including-ranges-cooktops/4810-how-check-continuity-ohmmeter.html] Thanks and Good Luck

Was this helpful?
