Part Number: AP3778485
MFG Part Number: 316418520
Made by: Frigidaire
Our Price
Regularly You Save
$275.43 $43.98

In Stock — Ships Monday Guaranteed

Questions & Answers

2 Questions & Answers

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and others. See all items in Range / Cooktop / Oven Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Appliance Compatibility Tool

Check your model number or use our Cross Reference Tool to determine if this part will work with your appliance.

Where can I find my model number?

Repair Help

Cross Reference Information

Part Number 316418520 (AP3778485) replaces 1064460, AH977982, EA977982, PS977982.

Have a Repair Question?
AppliancePartsPros has your Answer!

Repair Video

How to Replace Clock/timer #316418520

Step by step instructions on how to replace a Clock/timer #316418520 for Wall Oven made by Frigidaire. Note: This video is intended to give you the general idea of the part replacement procedure. Your appliance may differ depending on the manufacturer and model.


Comment on this video

Did you find this video helpful?


Questions & Answers

Ask a Question

Most Interesting

I own a Frigidaire over that was displaying "F10" error. I followed the service manual and measured the temperature sensor resistance, and it tested within spec. I then ordered a new EOC per the service manual. I installed the new EOC and now I have a new problem. The only functions that work now are setting the clock, the timer, and the oven light. The rest of the buttons don't do anything. I double and triple checked the wires that plug into the EOC along with the ribbon cables. I also verified that the part number on the new EOC matched the old unit. Although I did notice that the old EOC had a Revision M and the new EOC is Revision T. I have a background in avionics and I know that a lot of times when revisions do not match, you end up with compatibility issues. Is this what's happening here? Or is the new EOC simply defective? Any help would be appreciated.

Fadi N. for Model Number FEB27S5DSE


Was this helpful?

Could you advise how to get the ribbon cables to plug in to the slots. I know you have to squeeze the tabs on the sides to get it to unplug,but I can not plug them back in/

Jane for Model Number FEB30S5DBF


Was this helpful?
