Frigidaire 218428101 Door Handle - AppliancePartsPros.com

Total
$0.00

Part Number:	AP2114539
MFG Part Number:	218428101
Made by:	Frigidaire

Our Price
$18.75
Regularly	You Save
~~$22.54~~	$3.79

Most Interesting

Thia handle looks like the one I need. How can I change it? Do I have to take apart the inside of the door to get to the handle This is Ge profile refrigerator the handle is a long piece which have the white part handle attached to it.

Teresa C for Model Number TFH24PRSB-WW

Answer Teresa, To replace this handle, there are 2 screws at the top of the handle that you will remove. Once removed you will turn the handle sideways off the door and then push the handle toward the bottom to release the bottom screw.

Was this helpful?

Can you get these handles in black? We would like to change ours and maybe paint the fridge black.

Jason

Answer Hello Jason! The manufacturer is only listing the model in a white or bisque/almond color and does not offer an equivalent black model that we can suggest a part from. Sorry about that!

Was this helpful?

I would like to know where I can get the screw that slides into the slot at the bottom of the door handle. I do not know the size to ask for or where to find it. I have taken the one I have to various hardware stores and no one can match it.

Gloria A. for Model Number FRT17B3JW6

Answer Hello Gloria! The screw the slides onto the bottom of the door handle is part number 240521303. Thanks!

Was this helpful?

Latest Questions

How do you remove the handle from the door? The top is obvious with two screws. The bottom is streaming rust. How is the bottom attached? Thanks, Bruce

Bruce for Model Number FRT17L3FWT

Answer Hello Bruce, The handle is held on with screws on the one end and the other end is "slid" into a slot that technicians refer to as a "keyhole" slot. Once you get it off it's easier to understand but the screw on the front of the unit that attaches to the handle is just fitted into a slot in the back of the handle.

Was this helpful?

I purchased these handles with the block and screw inside,one for the freezer and one for the refrigerator. For the freezer, there are 2 screws at the top to mount the top of the handle to the freezer,(we have those) but please tell me what connects the bottom of the handle to the freezer door? Please tell me what "21A" is on the whole refrigerator diagram for these parts? Is this just a screw that should attach inside that block that is already screwed inside the bottom of the handle? I took the block and screw out of the handle and tried to attach it to the door of the freezer, but the handle does not snap to it. There is something missing here; there has to be something else that the handle attaches to in order to hold it to the freezer door, same goes for the fridge door. Any ideas? Thank you. Cindy L.

Cindy for Model Number FRT17B3AW4

Answer Hello Cindy! The block #73 218396700 is used on the top of the freezer door and the bottom of the refrigerator door. The screw #74 215503203 attaches the block to the handle The screw #21A 240521303 holds the block to the door. The bottom of the freezer door and the top of the refrigerator door screws in with screw #21 part number 240383406. Those should be the only parts needed to install the handles 218428101 to the door. Hope this helps you!

Was this helpful?
