Frigidaire 131553900 Dryer Heating Element Assembly

Total
$0.00

Part Number:	AP2107129
MFG Part Number:	131553900
Made by:	Frigidaire

Our Price
$63.27
Regularly	You Save
~~$75.29~~	$12.02

Most Interesting

Dryer has a broken knob also wont heat. Son said there was smoke and a burning smell maybe a new heating element.

Phil for Model Number ger341asl

Answer Phil, The timer knob part number for your unit is 131860001. For the not heating issue you will want to check the thermal fuse and thermostats to ensure that they are good. If you check them for continuity then you will need to replace the part. Also check the heating element to make sure that it has continuity. You will also want to make sure that the venting is clear from the blower wheel to the outside of your home.

Was this helpful?

What is the correct heating element for my model AEQ6700FS0?

Bill for Model Number AEQ6700FSO

Answer Hello Bill, The correct heating element for the model listed is 131553900.

Was this helpful?

Hi, my dryer was heating up and drying fine, now it will not heat. It takes about 3 cycles to dry clothes. It runs fine and does not shut as some of the other posts I read. The power is definitely 220. do you think the heating element is out? Thanks

Bill for Model Number Frigidaire Affinity AEQ6700FSO

Answer Hello Bill. If it is heating, It sounds like the venting system is clogged or kinked. You will need to check the vent and clean it out. Be sure and clean the vent pipe and the dryer air duct assembly. If the air flow is not good, the unit will retain moist air causing the clothes not to dry. Try running the unit with the vent unhooked from the back of the dryer and see if the dryer works properly.

Was this helpful?

Latest Questions

My dryer won't heat. Checked the vent no blockage, has the right power source. Would it be the entire heating element or is it like the old style dryers where the fuses go out and it won't heat.

Vance for Model Number fer6600fso

Answer Vance, You will want to check to make sure that the thermal limiter/fuse 134120900 has not blown. If it does not have continuity then it is bad. Also check for bad heating element.

Was this helpful?

My dryer heats up but not enough to dry the clothes. Is it the heating element?

Candis for Model Number fde436res1

Answer Hello Candis. You need to check the vent. It sounds like the venting system is clogged or kinked. You will need to check the vent and clean it out. Be sure and clean the vent pipe and the dryer air duct assembly. If the air flow is not good, the unit will retain moist air causing the clothes not to dry. Try running the unit with the vent unhooked from the back of the dryer and see if the dryer works properly.

Was this helpful?

My dryer runs but I have no heat?

Christian

Answer Hello Christian. Check and make sure you have 240 volts coming to the dryer. Check and make sure the unit is not set to Air Fluff. Also check the heater and thermostats and see if they are good. You can test these with a multi-meter TJMA-DM1. They should read closed for continuity. Here is a link on how to use a multi-meter. http://forum.appliancepartspros.com/oven-repair-including-ranges-cooktops/4810-how-check-continuity-ohmmeter.html

Was this helpful?
