Element

Note: This question is for the older version of this part, but we thought you might still find it helpful

Jose for Model Number 316224201

Answer Hello Jose, The same purpose of the little black wire is the same for the metal piece connecting the two prongs. There should be numbers on the terminals of the old that should match the terminals of the new.

Note: This question is for the older version of this part, but we thought you might still find it helpful

Don for Model Number TEF361GSA

Answer Hello Don. Yes, if the wiring on the unit is good, and the switch is new, you will need to replace the element 316135401.

Note: This question is for the older version of this part, but we thought you might still find it helpful

Don for Model Number TEF361GSA

Answer Hello Don. Check and make sure all the wiring is good on the unit. If so, and the switch is new, you will need to replace the element 316135401 on the unit.

Note: This question is for the older version of this part, but we thought you might still find it helpful

Steve for Model Number 316224201

Answer Hello Steve. No, you will need to order the correct element needed for the glass top and not the old one that is different. Most elements are different sizes and watts and will not interchange unless the model numbers of the ranges were the same. Hope this helps.

Note: This question is for the older version of this part, but we thought you might still find it helpful

Terry K for Model Number fef366esh

Answer Terry, "The procedure for servicing the smooth glass cooktop and surface elements is the same as in previous models. The front of the cooktop can be lifted by removing the two screws that secure it to the range chassis(in the top of the oven door opening). With the cooktop in the raised position the surface heating elements, warmer zone element and their wiring connections are accessible. The top can be held open by using a wood or plastic prop rod approximately 28 inches long. 1. Before removing the element be sure to note the locations of the element mounting clips in the support channel slot. The replacement element must be installed in the same position. 2. Carefully remove the wires from the element. Take note of the terminal identification on the element terminal block for each wire connection. 3. Before the element can be removed from the support channel the locking tab on the mounting clip must be closed 4. Remove the mounting screw that secures the element support channel to the cooktop. by squeezing shut with a pair of pliers. After the repair is complete the tab can be re-opened by using an awl or similar instrument. 5. Carefully pull the support channel away from the cooktop far enough to disengage the element mounting clips from the channel. Slide the element out from between the support channel and the cooktop. Reinstall or replace the element by reversing steps." Good Luck and Thanks

Note: This question is for the older version of this part, but we thought you might still find it helpful

Michael for Model Number fefl79dsl

Answer Hello Michael. Test and make sure the element is good. It should read closed for continuity. If it is good, test and make sure there is 240 volts coming to the range. If so, you will need to test and see where you are losing power at. You should have 120 volts on the element at all times, and get the other 120 volts from the control board 316557205. You can test this with a multi-meter TJMA-DM1. Here is a link on how to use a multi-meter. Hope this helps. http://forum.appliancepartspros.com/oven-repair-including-ranges-cooktops/4810-how-check-continuity-ohmmeter.html
