How do you replace the "glass oven door outer?
Answer Hello Tracey. To change the glass in an oven door, you will need to determine how to remove the door on the model number you are working on. If you open the door to the first stopping point, some oven doors will lift off the unit in this position. On other models, you will see clips on the back of the hinge toward the opening where the hinge enters the range. If yours is like this, you will open the door all the way open, then pull the clips down until they stop and lock in place. Then close the door to the stopping point and lift the door off the range. If you door does not lift off, and it does not have the clips, then you will open the door all the way open. You will see a hole in the hinge at the bottom of the door. You will insert a pin or nail into that hole and close the door to the stopping point. Then you can lift the door off the unit. Once the door is removed, you will lay it on a soft surface and disassemble the door. Pay attention and make notes if needed for reassembly of the oven door. Once you have replaced the door glass, you will reinstall the oven door back onto the range in reverse order of the way you removed it.
MY OVEN DOOR WONT LOCK SO IT CAN SELF CLEAN
Answer Dlay, Do you also have a error code in the display, when the door lock attempts to lock ? Can you hear the latch motor run when it attempts to lock ? Here's some things to look at: Check the wiring between EOC & Lock Motor Micro Switch. Check for binding of the Latch Cam, Lock Motor Rod & Lock Motor Cam. Check to see if Lock Motor Coil is open. If open, replace Lock Motor Assembly. Check oven door Light Switch - if open, replace.Replace the Motor Door Latch assembly if necessary. 316464300
