Pur-Beta Control

Pat for Model Number phs37ehsb1

Answer Pat, The control board for this unit does not need to have a new wire harness installed. It may have been redesigned but should still connect the same.

Note: This question is for the older version of this part, but we thought you might still find it helpful

A.w. for Model Number GLHS37EHSB8

Answer Hello A.W., You need to use an ac voltage meter to test for voltage at the control. You should use neutral for the reference point. This will be terminal P1-11. This is where one meter lead will stay during all three tests. The three test points are P1-1, P1-4 and P1-8. The P1-4 test will show no voltage unless you close the fresh food door switch. If the voltages are there, replace the control 241739709. If the P1-4 doesn't have voltage with the door switch closed, replace the fresh food door switch 240505801.

Note: This question is for the older version of this part, but we thought you might still find it helpful

Tony for Model Number GLHS68EGPB4

Answer Hello Tony, As long as you don't have a wiring harness issue, the part you ordered 241739709 should take care of the problem.

Note: This question is for the older version of this part, but we thought you might still find it helpful

John H for Model Number PLHS269ZCB3

Answer John, Your ADC (adaptive defrost control) board 5303918476 is located in the "control box" on the left hand side of the control assembly, in the refrigerator control asembly. You'll need to remove the filter assembly and the control panel to access the control. Good Luck and Thanks

Note: This question is for the older version of this part, but we thought you might still find it helpful

John for Model Number PLHS269ZCB3

Answer Hi John. You are experiencing a normal defrost failure. The defrost circuit power comes from the Adc board part # 5303918476. It will send the 120 vac to the defrost thermostat which closes at 14° or colder, it is part # 5303918214. If it remains open (very common failure) then the defrost heater part # 5303918255 cannot get the power to defrost the coils every 6-1/2 hrs approx. for 25 minutes. Thank You.

Note: This question is for the older version of this part, but we thought you might still find it helpful

Tony for Model Number glhs37ehsb6

Answer Hi Tony. Are you able to select the light on and off correctly as a simple indication that the control board is getting proper 120 vac from the connector at the top fzr. door hing area ? If not start there and inspect the molex connector individual pins as it is common the connections can be "miss-pinned" or burnt open. Make necessary corrections there if so by re pinning or just using butt splice with a wire to jump out the bad connection. Make sure there are no exposed wires so they do not short out. You can find the wiring diagram in with the controls in the fresh food area or folded in the front grill. Can you select the fountain control selections every time without fail ? Are they smooth and effortless as like when you first bought it ? If it is a difficult effort then the Fountain switch board is part # 241708306. Most likely ten it is not able to send the command selected to the board behind it called the Fountain control board which sends the actual voltage to the auger motor or to the or to the water valve to replenish the water tank as fast as the water is being used. Thank You.
