Frigidaire 3051163 Rear Drawer Glide - AppliancePartsPros.com

Total
$0.00

Part Number:	AP2121518
MFG Part Number:	3051163
Made by:	Frigidaire

Our Price
$2.58
Regularly	You Save
~~$11.05~~	$8.47

Most Interesting

I am getting ready to replace both the right and left front and rear glides on the drawer on my stove. However, I also see that there are two glides attached to the body of the stove. I need to know just exactly how many glides I need to buy and which ones to replace them all. I have no front glides on the drawer, one front glide on the frame where the drawer slides into the body of the stove, and one rear glide. I think my question is this: Do I need 4 front glides -- 2 for the drawer and 2 for the frame?

Brenda H for Model Number FGF354BGWC

Answer Brenda, You will need 2 front glides 3051162 and 2 rear glides 3051163.

Was this helpful?

I need to know the location for mounting the two rear glides. They were both broken and lying on the floor so am not sure of where exactly the new glides should be attached. Thanks for your help!!

Mary for Model Number 79095664100

Answer Mary, There should be 2 openings at the back of the drawer in which the rear glides will go into.

Was this helpful?

Someone used the oven drawer as a stepladder. I think the parts I need to replace are not on the drawer itself but the legs of the range itself. I can't find any info on these to replace them. Please help. Thanks.

Jamie for Model Number FEF366BCC

Answer Hello Jamie, you can order leveling leg 316129200 for your model. Hope this helps!

Was this helpful?

Latest Questions

do you have a diagram of how to attach part # ap2121518 and how the drawer works with the part.

Susie for Model Number fef357bsb

Answer Susie, Here's some help : "Removing storage drawer glides: There are four drawer glides mounted to the drawer, one on each side in the front and one on each side in the rear: 1. Press in on the locking tab (the curved tab) and pull the glide from the drawer. Reverse the procedure to re install. Thanks and Good Luck

Was this helpful?

I have the 2 bottom glides. Both top glides are gone. What 2 glides do I need for the TOP of my storage door?

Brian for Model Number fef365bgdc

Answer Hello Brian! For the rear drawer glide use part number 3051163. For the front drawer glide use part number 3051162. Thanks.

Was this helpful?

I need to know how to fasten drawer glides in rear.

Wallace for Model Number FEF316BSF

Answer Hello Wallace. You will need to put the curved end of the drawer glide 3051163 into the slot, and then snap the clip into place. Hope this helps.

Was this helpful?
