Frigidaire 3203459 Safety Valve - AppliancePartsPros.com

Total
$0.00

Part Number:	AP2131109
MFG Part Number:	3203459
Made by:	Frigidaire

Our Price
$185.24
Regularly	You Save
~~$218.58~~	$33.34

Most Interesting

Hi. When I turn on my oven the ingntor glows but the oven does not turn on for a while. Then you will smell gas. Do you know what this could be?

Eric for Model Number FGF326ASF

Answer Hello Eric. Test for 3.2-3.6 volts AC at the gas safety valve with the igniter turned on. If the voltage is there, you have a bad safety valve. If the voltage is low, you have a weak igniter and the igniter will need to be replaced. You can test this with a multi-meter TJMA-DMT3. Here is a link on how to use a multi-meter. http://forum.appliancepartspros.com/oven-repair-including-ranges-cooktops/4810-how-check-continuity-ohmmeter.html

Was this helpful?

This is a Tappan LP range. The stove top burners and oven both work fine independently. When the oven is on it is extremely difficult to impossible to light any top burner. If one does light it has a huge amount of pressure and eventually blows itself out. Any idea what the problem is? Thanks in advance!

Rank for Model Number 30-3649-23-03

Answer Hello Rank, This sounds like the regulator 5304416583.

Was this helpful?

There is a faint odor of propane inside the oven when the thermostat is off. I checked for leaks at all connections and didnt find any ???

Thomas for Model Number 79071105893

Answer Hello Thomas, If you are having an odor of propane inside unit then more than likely you have a faulty safety valve that is not closing fully.

Was this helpful?

Latest Questions

My oven recently stopped lighting, although the igniter was glowing red. When we tapped on the burner just above the safety valve, then it would light. I assumed from this that it was a bad safety valve. I pulled the wires off the safety valve and checked for continuity across it, which it has. Does this indicate that the valve is good, or could there be a problem/blockage in the valve orifice, and not necessarily an electrical issue? I also noticed that the pressure regulator valve above has a "switch" that when I cycle up/down lights the oven. This makes me wonder if this is the culprit and not the safety valve. If this is the case, why did the oven light when I tapped near the safety valve? Any suggestions? David

David for Model Number Frigidaire FGF316WGSA

Answer Hello David, You would want to do an amp draw on the ignitor. You should get 3.2 to 3.6 amps. If you do not get this reading then you would want to replace the ignitor. If you have proper voltage then it would be a bad safety valve.

Was this helpful?

i recently replaced an ignitor that no longer worked, did.t glow or even attempt to. noticed a spot where the ignitor wire had touched the metal frame and left a small burn mark. after putti.g in the new ignitor my oven will not turn off, it will go down to short small blue flames but never off. tried unplugging it and it wont turn off untill you close propane valve.

Adam for Model Number frigidaire fgf316dse propane

Answer Adam, You're on track, When the igniter wire shorted to ground, There was enough voltage to cause the bi metal switch, inside the safety valve, to warp, and it won't close completely. Repalcing the safety valve is the next step. Just Remember, Remove Power to the stove, before you start working on it.

Was this helpful?

My oven igniter wasn't coming on, I replaced it today with a new igniter and still nothing, no glow or anything, checked power with circuit tester and it has got power going to it, Could it be saftey valve?

Joe for Model Number FGF337EU

Answer Hello Joe. If there is power to the igniter, and it does not glow, you have a bad igniter in the unit. You can test this with a multi-meter TJMA-DMT3. Here is a link on how to use a multi-meter. http://forum.appliancepartspros.com/oven-repair-including-ranges-cooktops/4810-how-check-continuity-ohmmeter.html

Was this helpful?
