Is this screw the one that is used as a ground to the motor?
They do not show a specific screw for grounding the motor. The screw part number 131302800 would be for the vane inside the tub. You could use screw 5303015671 as a grounding screw.
Is this one or 2 screws?
Answer Hi Clay. The part # provided looks as this is only one screw. This part # is 131302800. Thank you.
Note: This question is for the older version of this part, but we thought you might still find it helpful
I have a G.E. dishwasher. No water coming inside. Changed timer, watervalve ,had micro switch tested, it tested good.How do you install flood float part#wd12x0334 and float stem part#wd12x0335. Thank you for your help.
Answer Hi Thomas. Comparing the breakdown, you should have a 1/4 " screw holding the Flood switch bracket to the bottom of the tub. Then (using your old one as comparison) you clip the wires of the old switch onto the new one. Then place the new switch in the bracket. The stem of the float will then pass through the hole in the top of the tub, through the bracket stem hole and carefully rest on top of the switch assembly. The bracket is part # WD12X10023. The switch is part # WD21X479. Thank you.
