What is the dimension of the part?
Answer Hello Mike,
This is about 19 X 30 1/4.
How do I get the door off? It will slide off of the hinges a couple of inches, but not all the way off.
Answer JD, you will need to determine how to remove the door on the model number you are working on. If you open the door to the first stopping point, some oven doors will lift off the unit in this position. On other models, you will see clips on the back of the hinge toward the opening where the hinge enters the range. If yours is like this, you will open the door all the way open, then pull the clips down until they stop and lock in place. Then close the door to the stopping point and lift the door off the range. If your door does not lift off, and it does not have the clips, then you will open the door all the way open. You will see a hole in the hinge at the bottom of the door. You will insert a pin or nail into that hole and close the door to the stopping point. Then you can lift the door off the unit. Hope this helps, thanks!
Note: This question is for the older version of this part, but we thought you might still find it helpful
What kind of adhesive will I need to secure this door (Part Number: AP3206038)?
Answer Hello Tony! There is no adhesive needed for the installation of the door glass WB57K10128. The part is held in by the side and bottom trims of the oven door. Thanks.
