Hinge Assembly

Total
$0.00

Part Number:	AP2635796
MFG Part Number:	WR49X5124
Made by:	GE

Part Number:

AP2635796

MFG Part Number:

WR49X5124

Made by:

Our Price
$34.64
Regularly	You Save
~~$53.40~~	$18.76

In Stock — Ships Monday Guaranteed

Quantity

Questions & Answers

4 Questions & Answers

Made by GE. GE brands include General Electric, Hotpoint, RCA, and others.
GE also makes various appliance models for Sears / Kenmore.

Appliance Compatibility Tool

Check your model number or use our Cross Reference Tool to find out if this part will work with your appliance.

Where can I find my model number?

Most Interesting

The right door no longer raises when it opens, thus, it no longer closes on its own. Which part makes it raise?

Marc for Model Number Hotpoint csx20e

Answer Marc, The cam is what allows the door to raise and lower. If one of the cams is bad then it is likely the other on the same side would be bad as well. You would need to get the Lower hinge kit WR13X10020.

Was this helpful?

frt refrig rt cam disintegrated. Is this a cam only appears riveted to hinge. Is hinge assembly wr49x5124 a two part assembly? Is ther also a shim?

Joe@healthinsuranceenterprises.com for Model Number tfx24fab

Answer Joe, The hinge comes with the cam assembly. It is a 2 part consisting of the hinge with cam riveted to it and with the upper cam.

Was this helpful?

This hinge assembly looks like the correct one, however, I can't tell if it will accomodate a drain hose to be threaded through it. Also, I had ordered the little black washer (shim cam?)but when I went to install it, the original one was riveted to the hinge. That is the part that I saw break, causing my freezer door not to stay closed, so I thought that this small washer was all that I needed. I'm just wanting to make sure of it fitting and will take care of my problem. Thank you for any help you can give. Clara part#AP2635796

Clara for Model Number TFX22RGB

Answer Hello Clara. Yes, based on the information you provided, it sounds like you will need to replace the hinge assembly WR49X5124. Hope this helps.

Was this helpful?

Latest Questions

Does the hinge assembly come with the shim cam? The hinge seems fine; should I just order the cam riser and shim cam?

Jimbeauga for Model Number TFX24RMA

Answer Hello Jimbeauga. No, WR49X5124 does not come with the shim cam WR2X6043. You will need to order it separately. Hope this helps.

Was this helpful?
