GE WH12X10141 Lid Switch Kit - AppliancePartsPros.com

Total
$0.00

Part Number:	AP2620150
MFG Part Number:	WH12X10141
Made by:	GE

Our Price
$21.42
Regularly	You Save
~~$34.14~~	$12.72

Most Interesting

About 5 minutes into the wash cycle of my washer, a loud clicking noise starts and last for a few minutes. Then the washer stops and sits for 3-4 minutes. When it begins again it does not continue on the wash cycle, but starts to drain and then spin (so my clothes are only getting washed for that initial 5 minutes). During the spin I hear the loud clicking noise again. It then continues through the other cycles and I don't hear the clicking noise again. What could be causing this?

Nora for Model Number wpse7003a0ww

Answer Nora, This issue sounds like it would be an issue with the control board on the unit. The clicking noise would be the relays on the board WH12X10138.

Was this helpful?

The start button is not working. We push it in and it is not turning on. Will part #ap3422790 / mfg. part #wh12x10225 be the right part?

John G. for Model Number wcse3100aww

Answer Hello John, You should first check the lid switch WH12X10141 and the lid switch magnet WH12X10092. These are trhe most common cause of the complaint you have listed.

Was this helpful?

My wash machine will go through the entire wash cycle and then stop after 10seconds on final spin cycle leaving the clothes still wet..what's up.

Tim for Model Number Wbse3120b1ww

Answer Hello Tim. Check the pump and see if it is clogged. If not, you will need to order and replace the control assembly WH12X10225 on the unit.

Was this helpful?

Latest Questions

My washer will complete wash cycle and then when it goes to spin out, it will stop. I can here the humming sound of the motor and I would lift the washer lid and close it back down and it would start, sometimes and other times it would not work, I would have to hit the start button to get it onto the spin cycle now nothing works. The humming is still there but none of my 2 options work any more.

Debbie for Model Number GE top loader

Answer Hello Debbie. Check and see if the pump is draining on the unit. If not, then it sounds like the pump is the issue of the no spin. If it is not clogged, you will need to replace the pump on the unit.

Was this helpful?

Our GE washser model # wbse2090 is skipping the final spin cycle and I hear the motor running specially with heavy loads but it does not spin. Pump and Agitator coupling just got changed and did not solve the problem. To get it started on the spin cycle I move the timer to the final spin cycle and push the start button more than once, remove some of the cloths and put them back after it starts spining. Is it the lid switch or Clutch that need to be replaced. Thank you

T.h. for Model Number GE WASHER WBSE2090

Answer Hello T H This would not be a lid switch issue but a clutch issue. The clutch WH5X256 and belt would need to be replaced WH1X2026.

Was this helpful?

The wash machine will fill and will not start wash cycle. Would this be the lid switch causing it not to start? Also sometime it will start washing and stop before it completes the cycle.

Jeff for Model Number whre5260e1ww

Answer Hi Jeff. Yes the lid switch senses the lid closed for safety. From the symptoms described then replace the lid switch. Lid Switch Kit - Item Number: WH12X10141. For the magnet assembly order WH12X10092. Thank You.

Was this helpful?
