Motor,inverter,electr

Part Number: AP4536552
MFG Part Number: WH20X10058
Made by: GE
Our Price
$269.04
Regularly You Save
$322.85 $53.81

In Stock — Ships Monday Guaranteed

Satisfaction Rating (2)

Questions & Answers

32 Questions & Answers



Genuine GE part. GE brands include General Electric, Hotpoint, RCA, and others. See all items in Washer Motor.
GE also makes various appliance models for Sears / Kenmore.

Appliance Compatibility Tool

Check your model number or use our Cross Reference Tool to determine if this part will work with your appliance.

Where can I find my model number?

More Product Images

Repair Help


Cross Reference Information

Part Number WH20X10058 (AP4536552) replaces WH20X10052, WH20X10045, 1810190, AH2577719, EA2577719, PS2577719, WH20X10034, WH20X10037, WH20X10041.

Do-It-Yourself Stories from Customers like You
Total Satisfaction Rating
(2)
View All Do-It-Yourself Stories Have questions? Ask our pros!
Ge washing machine was not agitating and not spinning?? other function were working nicely the motor green led indicator was flushing 6 time?? Mohammed A. • Brevard, NC • November 06, 2014
Appliance: General Electric Washer WJRE5550H1WW

My Repair & Advice

Was this review helpful to you?

Most Helpful Stories

7 People found this story helpful
Do-It-Yourself Rating
  • 1
  • 2
  • 3
  • 4
  • 5
Easy Difficult
Repair Time Estimate

15-30 minutes

2 People found this story helpful
Do-It-Yourself Rating
  • 1
  • 2
  • 3
  • 4
  • 5
Easy Difficult
Repair Time Estimate

30-60 minutes

Have a Repair Question?
AppliancePartsPros has your Answer!

Questions & Answers

Read all 32 Questions

Ask a Question

Most Interesting

I have a 3 flash error code on my WH20X10066 motor. I know the diagnostic sheet says Corrupted software and to replace the motor. Is there a way to reset this and have it work again or is it completely dead? Any help would be appreciated. Thanks

Andrew for Model Number GTWN5050M0WS

Answer

Was this helpful?

Model= WJRE5500G0WW Two days ago after a leaked seal that I replaced last year, my washer stopped spinning and agitating. It has no LED light on it. I cannot find any fuse anywhere. It fills up accurately to whatever level that it’s set at and drains after long hesitation (hesitation I guess equal to on the amount of time knob set for cleaning cloth). I changed the electronic board last year. I reset the washer by opening and closing the lid correctly again today. The belt and pulley can rotate bidirectional without any sound with correct belt tension. How can I rule out other causes except the drive motor (original WH20X10037 with LRA 6.1)? Also how do I check to see if enough voltage is getting to motor?

Tony for Model Number WJRE5500G0WW

Answer

Was this helpful?

Washer only spin slowly. Check lid switch and belt=OK. Easy rotation of agitator on both way. Motor diagnostic led 9 short flash. Reset motor code but still spin slow and error code came back. I ordered a new motor. Before I replace the motor, what are the other verification I should perform? Why has the motor failed? Can you tell with the serial number how old is the unit? My serial is VS161628G. Thanks!

Dan for Model Number WWSE5240GWW

Answer

Was this helpful?

Latest Questions

My motor does not run. I have sought out the error code but I see no flashing LED. I have seen many "how to" videos and know where the light is located. However, there is no flash.

Aron Sanders for Model Number WLSR3000G0WW

Answer

Was this helpful?

I'm getting 4 flashes on the motor, and the mode shifter coil is open. I bought a new GE mode Shifter for replace. It Burned again. Do i need to replace a new GE Motor inverter and The Mode Shifter in the Same Time. My Motor Mode is 175D5106G065.Thank You for Your Answer.

Johnathan for Model Number GTWN5050MOWS

Answer

Was this helpful?

Hello - my washer does not spin or agitate...it is a GE WPRE6100G2WT & I am looking for the correct motor part number for this machine, unfortunately I was not able to locate it on the item. Where can I look for it or are you able to suggest a part # for this motor in order to be replaced?

Alonzo C. for Model Number WPRE6100G2WT

Answer

Was this helpful?
