Please, could you let me know to which connector number (M1,M2,M3,M4,M5;M6,M7) of the Switch over the motor is connected the internal yellow cable from the motor? I can´t see it in the photo of the ad. Thanks from any help. Regards, Neto
Neto for Model Number WH20X876
Answer Hello Neto,
If you could please include your mode number from the machines' I.D. tag, we can then pull the wiring diagram and give you an accurate answer. You listed the part number where the model should have been listed. Thank you for your understanding in this matter.
I HAVE THE MOTOR WITH #5KH41MT26S ON IT. THE ONES YOU ARE PROVIDING WITH #WH20X876 AND # 5KH41MT26AS ON IT. IS THAT CREATES A PROBLEM? BECAUSE IT IS NOT WORKING.THANKS.
Ali G for Model Number WISR309DTBWW
Answer Ali, The part number you supplied WH20X876 indicates your washer motor is an "export" model and operates on 220 V-50 hz. is this the type of power supply you have ? you may have the wrong part if not. You will need to check the white tag on the original motor, to check the electrical rating on the plate. also check the service part number WH20X*** this will establish the proper motor needed when that number is cross referenced. You may have the incorrect motor in your washer
