Part Number:	AP2065182
MFG Part Number:	WR17X2891
Made by:	GE

Our Price
$11.36
Regularly	You Save
~~$20.72~~	$9.36

Most Interesting

Hello, I want to purchase the plastic tube but not sure if this part could replace the tubes that come down the water assembly, It has two plastic tubes from the assembly to the water valve which are broken and so is the large plastic hose that goes to the ice maker model number is csx25mrcgww. My question is if the plastic tube that i want to buy is the right one or is it a different one that I need to buy or do I also need to buy the whole water assembly because i see that the water assembly comes with all the plastic tubes. Please I need you help. Thanks, Jeannette

Jeannette for Model Number csx25mrcgww

Answer Hello Jeannette. WR17X3670 is the tube that runs through the freezer door. The water tank WR17X10507 goes under there and the tubes [Part Number AP2065182].

Was this helpful?

What is the OD of this tubing? And what material is it?

Dave for Model Number pcf23ngtecc

Answer Dave, the tubing WR17X2891 is a 5/16" plastic tube. Thanks!

Was this helpful?

What is the OD of this tubing?

Dave for Model Number pcf23ngtecc

Answer Dave, the plastic tube WR17X2891 is 5/16. Thanks!

Was this helpful?

Latest Questions

Hi, I am replacing the entire water line (except the part that runs through the freezer door, that as I read it cannot be replaced) Beside part WR17X3105, how many of WR17X2891 do I need, one or two? the diagram shows it twice (n. 810). Thanks.

Nicola for Model Number TFX20JRBAWW

Answer Nicola, you will need two plastic water tubes part number WR17X2891. Thanks!

Was this helpful?

Hi, My water dispenser tube that runs through the freezer door is leaking and I want to replace one. I checked the diameter for this tube should be 5/16 and this tube WR17X2891 looks identical to the tube I wanted to replace. But this tube WR17X2891 does not seems to be compatible with the model number I presented. Please adivse: 1. the length of this tube 2. whether I could go ahead to buy this tube as replacement for my water dispenser tube that runs through the freezer door. Thanks Liang

Liang for Model Number GSS22SGRBSS

Answer Hello Liang, The water tube that runs through the freezer door is foamed in place and cannot be pulled out to replace. You would have to replace the freezer door WR78X11098 on the unit if the water line is broken inside door..

Was this helpful?

ice maker stop working.I replaced dual water valve,how long will it take to find out if that was the problem. the led light stays solid,and i do get water from the water dispenser.

Chuck for Model Number 363.57552791

Answer Chuck, It usually takes a couple of hours for the ice maker to cycle, and clear the remaining air and water from the system. You may want to start the icemaker yourself. You can remove the cover and slowly and carefully turn the main gear in the clockwise direction, until it starts to advance on it's own. or you can press down on the ejector / rake arm until it starts to advance. You'll want to let it make a few more cycles, then throw the cubes out. Which red light are you describing ? on the dispenser ?

Was this helpful?
