Round Igniter

John for Model Number ddg7987rbl dryer

Answer Hello John, You would want to lift the main top of unit, take the front panel off and replace from the front with front panel removed. To remove top there are screws that hold main top to the front when you open door. Remove the screws and lift top. Once top is lifted you will remove screws that hold in front panel.

Bill for Model Number DLL1550BEL

Answer Hi Bill, the wiring diagram is normally on the back of the unit or inside the cabinet. Hope this helps!

Harvey B. for Model Number DDG7987RAL

Answer Harvey, the screw listed as SCR 6-20 AB HXW 1/2 S. The igniter is mounted with the clip WE1X941. Thanks!

Harvey B. for Model Number DDG7987RALWH

Answer Hello Harvey. GE does not offer any information on removing the burner WE14M104 in this model. According to the instructions, you will remove the igniter bracket assembly by removing 1 hex screw from the dryer, and should not need to remove the burner. Hope this helps.

Andywong for Model Number DDG5180RBLWH

Answer Hi Andy. It is very commonly the first part to fail on any gas product. The igniter is part # WE4X444. If the mounting clip is burnt order WE1X941. Thank You.
