I am replacing the 3 speed blower switch and the wires were off when the original switch was damaged. There are 4 wires, blue, red, black and white with red stripe. Which terminals to they attach to? Thank you
Answer Hello Kristen,
As per the tech sheet, the blue wire goes to terminal 5, the red goes to terminal 4, the black goes to terminal 3, and the red with white trace goes to terminal 1. As per the tech sheet, there are no wires connected to terminal 2.
