Thermostat Def

Total
$0.00

Part Number:	AP3884325
MFG Part Number:	WR50X10069
Made by:	GE

Part Number:

AP3884325

MFG Part Number:

WR50X10069

Made by:

Our Price
$7.67
Regularly	You Save
~~$15.05~~	$7.38

In Stock — Ships Wednesday Guaranteed

Quantity

Questions & Answers

3 Questions & Answers

Made by GE. GE brands include General Electric, Hotpoint, RCA, and others. See all items in Refrigerator Defrost Thermostat, Sensor.
GE also makes various appliance models for Sears / Kenmore.

Appliance Compatibility Tool

Check your model number or use our Cross Reference Tool to find out if this part will work with your appliance.

Where can I find my model number?

Most Interesting

Hi, what the difference between the thermostat defrost, model number WR50X10068 and WR50X10069 for the GE Profile Refrigerators. They look identical and the WR50X10068 appears to more easier to get.

Dan for Model Number psc25nswass

Answer Hello Dan, The difference between the 2 may be the temperature ratings. The one for your unit calls for an overtemperature thermostat of between 110 - 140 degrees. Both parts are available and both will work for your unit.

Was this helpful?

If the defrost thermostat fails to open, will the heater time out and be shut off by the board.(What is max. defrost time?) I assume the defrost is cycle initiated by the board at some specific interval. Would this allow the ice to melt and freeze in a clump(stalagmite) in the freezer compartment and there be no noticeable thawing of items in the freezer. All temperatures appear to stay in normal ranges. Are there any other issues if the defrost thermostat malfunctions? Will the unit go into defrost if the defrost thermostat doesn't close? I think my problem is the thermostat doesn't aways open soon enough???

Bobh for Model Number PCF25MGWABB GE Side by Side

Answer Hello BobH. If you are getting an ice problem like you are describing, then the issue sounds like a water leak issue and not a defrost issue, or the drain is clogged and the water is not draining. Again, it does not sounds like a defrost issue. I would start with cleaning out the drain tube. Hope this helps. http://forum.appliancepartspros.com/refrigerator-freezer-repair/173916-kenmore-top-mount-refrig-h2o-build-up.html

Was this helpful?

Defrost cycle lets ice melt before starting back up. How does this thermostat effect this cycle?

Bobh for Model Number PCF25MGWABB GE Side by Side

Answer Hello Bobh. The defrost thermostat WR50X10069 is designed to open when the temperature of the coils reach a certain temperature and turns off the heater. Hope this helps.

Was this helpful?
