GE WR17X4358 Water Tank - AppliancePartsPros.com

Total
$0.00

Part Number:	AP2066390
MFG Part Number:	WR17X4358
Made by:	GE

Our Price
$38.55
Regularly	You Save
~~$53.84~~	$15.29

Most Interesting

I understand how to make connection from AP2066390 to water solenoid on the upstream side, but how do you make the connection to the icemaker/water dispenser on the downstream side?

Stu H. for Model Number TPX24PP

Answer Hello Stu, The ice maker does not connect to the water reservoir. The line comes under the unit to the water connection at the door hinge.

Was this helpful?

How do I attach the new tube from the new replacement water tank to the water valve since the replacement is smooth with no screw for the threads? Is there an adapter for my new tank hose to make it fit over the threads on the water valve. I got the 5/16 Carl guess tube fittings but don't see how this helps me with holding the tubing into the water valve? Thx

Bryan for Model Number TPX24PBBA

Answer Hello Bryan, If your water valve is threaded then you will need to use the fitting that was on the old tubing to connect the water line.

Was this helpful?

I replaced the water tank, mover the ice lever to the down position, and held down the water dispenser button in the door for over 2 minutes. No water. I double checked to make sure I hooked up the tank properly. Why no water?

Joe for Model Number tpx24pr

Answer Hello Joe, Two questions: Did you turn the water back on? Do you hear the water valve energize when the water dispense button is depressed? If yes to both questions, you should check the water filter. If no to the second question, you should check for an electrical problem at the valve, the door hinge, or at the dispenser button. If no to the first question, turn the water on.

Was this helpful?

Latest Questions

Our water has a terrible taste.I was told replacing the water reservior and tubing should remedy this.The ice does not have this same bad taste.What do I need to order to take care of this problem?

Rod for Model Number gsl22jftebs

Answer Hello Rod, The first thing that you want to do is to make sure that your filter MWF has been changed. Also check to make sure that the water has been flushed good. The water tank WR17X4358 could make the water taste bad but in general it has no way to cause this as the tank is made of plastic and do not give odor or taste.

Was this helpful?

I need to replace the tubing from the water tank to the water valve. How do I get the tubing off of the water tank???? Do the tubes disconnect some way or do I need to replace the water tank??? I'm looking to use tube # WR17X2891. Is that correct??? Thank you for your help.

Mary S for Model Number 363.58097890

Answer Hello Mary. You need to remove the tube from the filter housing and the bottom of the door on the freezer door. You can not remove the lines from the water tank. You will need to order the water tank WR17X4358 and replace the tank. You can not replace just the lines.

Was this helpful?

Model Number: TFX22CRXA-AA Brand: GE Age: More than 10 years. Hi there! Dustin (?) from your main phone number asked me to post this question here (?, or on the forum - I posted there and haven't heard back). Hope you can help! I ordered and rec'd a replacement water tank (with tubes) for leaky original - tank had leak, tubes were fine. Order # 2147344 Part # AP2066390 Got the new tank installed but not sure how to reconnect the tubes. The replacement tank that was sent is exactly as the picture on your site: tank with 2 tubes that just cut off (no connecter on the ends). At the end of the original tank tubes, there was a screw-on connector that joins tank tubes to main & freezer door tubes. I thought I could just cut original connectors off and reuse on the new tubes BUT, the new tubes are completely straight/smooth - not like the original tube endings that had a grooved notch & raised "stopper" ring that keeps the connector stable on the tube. The new tubes i rec'd have two black lines market on it but that is it - no groove/stopper. I'm afraid if I install this "as is" with no "catch" the water pressure will force out the tube when I turn the water back on. There were no instructions with this tank. Today, I went to a plumbing supply house, talked to appliance repair center, spent 1 hour on phone with GE and nobody knows what i should do. Please advise and thanks so much!! Lori

Gargamel for Model Number TFX22CRXA-AA - GE frig

Answer Hi Gargamel. I understand the water tank hose ends are cut squarely as the new styles are. They replaced the union(compression) Style connector you described. You will need to use push on connectors that have floating garter ring connectors hanging from each side . IMPERATIVE to cut each opposing hose exactly square as the new hose is. As the hose is pushed tight in the new connector ( John Guess ) type The inner garter ring will grab and compress the hose as needed. 5/16" to 5/16" connector is part # WR02X10471. 1/4" to 5/16" connector is part # 4373559. Let us know if we can assist further. Thank You.

Was this helpful?
