I am replacing the assembly sensor for my washer but I cant find were the bracket is to replace the sensor. Please help me with were it is located on my washer.
Answer Hello Brenda. Unscrew the 4 screws from the back cover. Unscrew the single screw from the lower-right
side of the cabinet. Disconnect the connector from PWB Harness. Remove the bracket assembly 4811ER3001A from the unit.
What is this sensor commonly known as?? What is its function??
Answer Hello Becky. 4811ER3001A is the vibration sensor and is used to detect off balance loads.
