Ice Funnel

Part Number: AP4436124
MFG Part Number: 3016JA2002C
Made by: LG
Our Price
Regularly You Save
$3.53 $0.59

In Stock — Ships Today Guaranteed

Questions & Answers

4 Questions & Answers


Due to manufacturer changes you must also order the frame 3210JA0006S to make this work. This funnel now only has four tabs instead of six.

Genuine LG part. See all items in Refrigerator Ice Door Or Ice Chute.

Appliance Compatibility Tool

Check your model number or use our Cross Reference Tool to determine if this part will work with your appliance.

Where can I find my model number?

Repair Help

Cross Reference Information

Part Number 3016JA2002C (AP4436124) replaces 1266772, AH3517826, EA3517826, PS3517826.

Have a Repair Question?
AppliancePartsPros has your Answer!

Repair Video

How to Replace Ice Funnel #3016JA2002C

Step by step instructions on how to replace a Ice Funnel #3016JA2002C for Refrigerator made by Kenmore, LG. Note: This video is intended to give you the general idea of the part replacement procedure. Your appliance may differ depending on the manufacturer and model.


Comment on this video

Did you find this video helpful?


Questions & Answers

Ask a Question

Most Interesting

You show this part in white, I need Black

Nanhaller for Model Number LRSC26923


Was this helpful?

The 4 prongs on this part are different than the one that came off of my refrigerator even though the part numbers seem to match up. Is there another part # for what I am trying to replace or do I need to replace the part that this attaches to? The following link shows what I have on my old part: https://dl.dropbox.com/u/3032591/AppliancePartsPros.png

Brian M for Model Number LG LRSC26915SW


Was this helpful?

Someone already asked this before but I will ask again since your answer doesn't seems accurate. The funnel only shows 4 clips, yet, your page says that due to changes on the manufacturer side another part needs to be ordered, when I try to match the funnel to my model number it tells me that the part will fit my refrigerator (I know it would not because we just got it in the mail and it does not fit), but when I go to the attachment that needs to be ordered for the funnel to work your system tells me the part is not compatible with the refrigerator, which is it? I need the part or I don't?

Sobeida for Model Number LRSC26912SW


Was this helpful?

Latest Questions

P/N 3016JA2002C, your picture only shows 4 prongs on the back side that snap in. My part has 6 prongs. Can you tell me if your picture is wrong? I have had this problem before and the 4 prongs do not even come close to working because the 4 prongs are too big and will not fit.

Jabro J. for Model Number LRSC26912sw


Was this helpful?
