Inside lite will not come on with either door opened. Can push switch quickly and lite will glow for a second (if that long). Replaceing both switches (if thats the problem) does not bother me. Please let me know and if thats the problem how do you get to the swiotches. Thank You, Jack Greider
Answer Jack, You'll want to remove the upper hinge covers and check the wiring and connections at the door switches. and that the switches and covers aren't loose or shifting. Then check or replace the lamp socket assembly 6621JK2003B and make sure there are no loose connections in the harness or connectors. Thanks
Disconnected both switches and lights are still on. It shows on the switch to be NC (normally Closed) contact and "Opens" when pressed. The lights remain on with them disconnected. What now?
Answer Hello Barry. According to the manufacture, you will need to replace the wiring harness 6621JK2003B and the main PCB EBR34917104. This is causing the lights to stay on all the time and not shut off. This can also melt the inside of the unit. Hope this helps.
How to remove push switch from the wire harness, that is, how to separate the two so that the switch can be replaced?
Answer Hi Linda. Remove power.Examine the new switch to compare instructions. There are 2- mount tabs that purposely push out right behind the panel where it is installed. You can take a plastic putty knife under the front sides to push in and release the inner mount tabs. Push one in and gently pry one side out. Hold this with one finger and then do the same with the other side. With the switch in hand, use a small screwdriver to release the wiring connector terminal locking clip and pull back on the terminal case. This will release the wire clip from the switch body. It will only plug in one way as it is formed that way. The switch is part # 6600JB3007E. Thank You.
