The door has stopped latching. The latch does not appear to be damaged, but moves up and down freely. I was given a part number for a spring. How do I check inside the door to make certain this is the part I need?
To open the door to check the spring you would need to use a flat blade to go around the perimeter of the inside of the door and pop inner door out. You will want to inspect the latch for a broken clip that would hold the spring and check for a broken spring.
Ho do you install the door key and the spring DE61-00048A and
Answer Hello Sandy. 1. Open the Assembly Door by degree 90º
2. Seperate lifting Assembly Door from Set. 2. Insert flat screwdriver into the gap between Door
“A” and Door “C” to remove Door “C”.
• Becareful when handling Door “C” because it is
fragile. 3. Detach the spring and key door from Door.
I have a Kenmore 401.85044010 Is this the spring for the door latch assembly?
Answer Hello Dan, spring part number DE61-00048A is the spring used on the door key which can be considered the striker. Thanks!
