Part Number:	AP3176314
MFG Part Number:	8184858
Made by:	Whirlpool

Our Price
$32.16
Regularly	You Save
~~$45.86~~	$13.70

Most Interesting

Can you advise how the trim pieces fit over the glass? When I try to put them on the glass will not go behind the trim.

Guest

Answer Hi! The glass will go behind the top and bottom trims but will rest on the top of the side trim. Thanks!

1 person found this answer helpful.

Was this helpful?

The side trim parts are 8523171 and 8523165, sold individually? Are the parts that are included in this kit the same parts that can be purchased individually under the above part numbers? If the same, it appears I can order the kit for a little bit more than just one piece of side trim.

Cathy for Model Number WFG510S0AB1

Answer Cathy, the oven door trim kit 8184858 is not suggested for your model WFG510S0AB1. You'll need the right side trim 8523165, left side trim 8523171, and the bottom door trim 8523177. Each part comes one per package. Thanks!

Was this helpful?

I am looking for the side trim peice and the trim vent piece that the oven door handle attaches too. When I put in my model number it brings up the parts that, I assume, fit the model number. Your compatibilit tool says otherwise. Are these parts listed that my model brings up compatible or not?

Cathy S. for Model Number WFG510S0AB1

Answer Cathy, according to your model the right side black trim is part number 8523165, the left side trim is part number 8523171, the top vent trim is part number W10310922 and the bottom is part number 8523177. Thanks!

Was this helpful?

Latest Questions

The top over door has 4 rubber seals. The top and bottom seals are 22 in while the two side seals are 13 in. The seals are in the middle of the inside door and held by clips. The seals have dried up from years of use. Can you help?

Bill Mclaughlin for Model Number Magic Chef double oven Model 24FA-6CKXW

Answer Hello Bill, you need to order top and bottom seal 7212P006-60 and side seal 7212P007-60. Thanks!

Was this helpful?

I want to make sure this kit will support the outer glass panel of the oven door; mine have rusted and and the door can fall soon.

Haydee R. for Model Number GR399lx61

Answer Haydee, yes, the oven door trim kit 8184858 will fit the GR399LXGB models. Thanks!

Was this helpful?

Hi. Recently I ordered the trim-door part 8184858. The kit came with 2 side trim pieces and a bottom piece (that holds the glass) but it actually looks like 2 bottom pieces. Do I use both together? When I do, my original screws aren't long enough. I understand the trim not being screwed into that, but I just can't figure out the bottom piece or pieces. Please help.

Jbop for Model Number Whirlpool Oven 465

Answer Hi. Color: Black. For white order 8184859. For bisque order 8184860. For almond order 8184860. Kit includes two side pieces and one bottom piece. NOTE: This part has been redesigned by the manufacturer. The lower screws are no longer used and the side trim now locks into the lower trim with the dimples on the lower end of the side trim. On one bottom piece there are more trim screw hole's to use depending on your model. Thank You.

Was this helpful?
