The piece that latch the door is broke the top one, can it be replace, if so how? And what kind of screws is that on the frame of the inside of the door to where the latch is in?
With the upper door strike being broken off you would need to replace the door on the microwave part number W10211464. To do this you will need to remove the air grill at the top and loosen the upper door hinge. Once loose you will be able to take the old door off and install the new door.
Are these the self alligning screws that are used to secure the microwave to the cabinet above the microwave? If not what is the correct part number? Thank you!
Answer Hello Sander,
The only way to get the mounting screws you need is by ordering part number 8206614. This is installation kit which includes four mounting screws and the other hardware for the installation of these units.
I ordered a replacement door for our microwave. I received it, but I see no way to remove the mounting bolt. No allen wrench seems to fit it. Can you help? Thanks.
Answer Hello Jerome. 1. Unplug microwave oven or disconnect power.
2. Remove the air grille. 3. Remove the 1 T-10 Torx® screw from the top
hinge of the door.
4. Lift the door up and off the other hinge to remove
the door 8206395. Hope this helps.
