Tubing 3/16

Part Number: AP4095552
MFG Part Number: 74006335
Made by: Whirlpool

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Appliance Compatibility Tool

Check your model number or use our Cross Reference Tool to determine if this part will work with your appliance.

Where can I find my model number?

More Product Images

Repair Help

Cross Reference Information

Part Number 74006335 (AP4095552) replaces 3414F077-44, 895686, AH2084021, EA2084021, PS2084021.

Have a Repair Question?
AppliancePartsPros has your Answer!

Questions & Answers

Ask a Question

Most Interesting

need to order the 3/16 " hose with the brass fittings because one of flanges cracked. From what I can determine the part number is 74006335 I believe but has been discontinued. What is the appropriate substitute and where can I order it. Thank you Vince

Vince for Model Number CLY1610ADW


Was this helpful?

The pilot light lights, but the oven does not come on. Mechanic said to replace the mercury switch. What is that part number? Thanks, Chris

Chris S for Model Number 16RW3BT49


Was this helpful?

I need the line that runs from the top of the stove to the broiler unit. The outside diameter is 3/16 of an inch. Is this my part? I don't know what OEM means.

John K. for Model Number BT16RA-3B


Was this helpful?

Latest Questions

I need the gas tube for the pilot light that runs from the oven control valve to the pilot light. Will part # AP409552 work?

Arlan for Model Number CLY1610ADB


Was this helpful?

I need the 3/16" gas tube (with fittings) that goes to the oven pilot. It has to be about 44" long. Does your part AP4095552 meet this? A replacement part I received from another company was only 37" long.

Mike for Model Number CLY2220ADB
