Whirlpool 67006322 Valve, Dual Water - AppliancePartsPros.com

Total
$0.00

Part Number:	AP4081950
MFG Part Number:	67006322
Made by:	Whirlpool

Our Price
$59.05
Regularly	You Save
~~$75.26~~	$16.21

Most Interesting

My question was answered 23Jan13. This is a follow-up. I tried to tighten the filter I had replaced a week ago as suggested and it would not yield further. However I replaced the filter with the by-pass cover and everything worked fine. Would this indicate a faulty filter (it was new a week ago) or faulty filter head assembly?

Luis for Model Number MFI2568AES

Answer Hello Luis. Based on the information you provided, the filter head will need to be replaced on the unit.

Was this helpful?

Noise generated 1-2 seconds when dispensing water and ice-maker is refilling, pressure drops to a trickle. Changed the filter with no effect. Checked supply line and there was little pressure. Line upgraded, pressure resored. Removed water tank, saw bubbles on all 5 sections. Tank immersed in hot water for 10 minutes, reinstalled, no effect. Dual water valve replaced, no effect. Ordering the tank today. Do you know of any other sources that could generate a loud vibration noise behind the plastic cover of the tank and filter assembly when water is dispensed and ice-maker refills?

Luis for Model Number MFI2568AES

Answer Hello Luis, If the water filter is not fully seated it will make the noise. Try to turn the water filter just a little more. If it turns then try the water and see what it does. If still making noise then tank is what would be needed. It comes with the filter head.

Was this helpful?

Replaced filter no water or ice, install bypass plug made no ice but dispensed water now won't dispense anything has good water pressure. Unloaded turned off for day still nothing dispenses. Disconnected water line water drains out water line when pushing dispenser. I think that the water valve is bad (diaphragm in valve is soft and swollen), but I don't know if that would cause it not to dispense with a new filter, or do I have more or different problem?

Doug for Model Number afi2538aes3

Answer Hello Doug, The first thing I would check is the water valve. With a multi-meter you want to check to make sure you are getting power to the valve. First check the dispenser valve 67006322, you should get 120vac. Then check the icemaker valve to ensure you are getting 120VAC. If you have the bypass plug in and you are getting 120vac to both then you have a bad filter head 12956202 and would need to replace it. The water valve is located behind wall in fresh food section. The filter head comes with tank. You can test this with a multi-meter TJMA-DMT3. Here is a link on how to use a multi-meter. http://forum.appliancepartspros.com/oven-repair-including-ranges-cooktops/4810-how-check-continuity-ohmmeter.html

Was this helpful?

Latest Questions

I replaced the water valve on this unit. Now, I don't get any water from the water dispencer and icemaker doesn't make any ice. Please advise. Thank you

Ali for Model Number MAYTAG MSD2732

Answer Hello Ali. Check and make sure you turned the water back on after replacing the valve. If so, you may need to check the filter in the unit and make sure the water tank isn't frozen.

Was this helpful?

I think I have a bad valve. My water dispenser dispenses water very slowly. There's no problem with ice maker, and there's good water pressure from the source. I understand I should read 500-500 Ohms on the valves. I measured nothing on one valve, and <200 on the other.

Jeff for Model Number P/N: 67006322 dual water valve

Answer Hello Jeff, The resistance of the valve is really beside the point because the electrical resistance has nothing to do with the physical/mechanical workings of the valve. If it's dripping and you haven't changed a water filter recently, the issue will be resolved by replacing the water valve. If you have changed a water filter recently, you have to throw about 2 gallons of water away to purge the air from the system. The water valve will not close properly with air in the system.

Was this helpful?

The water line was blown out with compressed air and the unit was un plugged in the Fall as we typically do. After the unit was plugged back in once we returned and water supply was turned back on, the water dispenser was fine but after several hours and now weeks no ice. I also don't recall hearing water filling the tray. Where do I start?

Al B. for Model Number Maytag MF12568AES

Answer Hello Al. Check and make sure the icemaker is turned on and if so, that the icemaker is cycling. If the icemaker is cycling and there is power to the water valve, but no water, you will need to replace the water valve 67006322. You can test this with a multi-meter TJMA-DMT3. Here is a link on how to use a multi-meter. http://forum.appliancepartspros.com/oven-repair-including-ranges-cooktops/4810-how-check-continuity-ohmmeter.html

Was this helpful?
