Expert tips for testing & replacing the mechanical timer in an electric Kenmore dryer

Tired of dealing with a dryer that won’t start or stop? Learn how to test and replace the mechanical timer in your Kenmore electric dryer, and skip the call to a repair pro!

If you need any replacement parts for your Kenmore dryer, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Important: The troubleshooting information in this article is based on model 11068722700 and may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What you need

• Putty Knife
• 1/4 inch nut driver
• Multimeter

Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Safety precautions

Your safety should always be the top priority when performing any appliance repair.

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.
• Don’t test live voltage with a multimeter if you’re unfamiliar with how to prevent short-circuiting.
• Consider wearing safety glasses and/or a dust mask when working with chemicals, dust or a large amount of debris to prevent irritation or injury.

Read more: 9 ways you can maintain your dryer to prevent common problems

How to test and replace the mechanical timer on a Kenmore electric dryer

Step 1. Test the timer

1. Use a putty knife to push in the two clips that hold the console in place.
2. Push the console upward and back to access the timer.
3. Locate the contacts labeled BLK and BU on the timer.
4. Turn the dryer to a setting where it would normally be running.
5. Use a multimeter to test the contacts for continuity. If there is no continuity, the timer is defective and needs to be replaced.

Step 2. Remove the timer

6. Take a picture of the wires connected to the timer to ensure proper reconnection later.
7. Reach around and remove the timer knob.
8. Remove the two screws that secure the timer in place.
9. Take out the defective timer.

Step 3. Replace the timer

10. Install the new timer by securing it with the two screws.
11. Reconnect the wires according to the picture taken earlier.
12. Reattach the timer knob.
13. Snap the console back into place by pushing it forward until the clips lock in position.
14. Test the dryer to ensure the new timer is working properly.

Read more: 7 possible reasons why your electric dryer won’t shut off

Additional information

Thanks for reading! We hope this guide helped you test and replace the door switch in your Kenmore dryer.
