How can I replace the heating element in a Speed Queen dryer?

In a dryer, the heating element (also known as a heater) generates heat so the machine can dry your laundry. Over time, regular use and wear can cause the heating element to wear out or become damaged.

You might need to replace the heating element if your Speed Queen dryer doesn’t heat up properly, laundry items are taking longer to dry, or the heating element appears to be visually damaged or worn.

Fortunately, with a few basic tools, a new part and some patience, you can tackle this repair yourself and get your Speed Queen dryer back in working order. Let’s get started!

If you need any replacement parts for your Speed Queen dryer, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Important: The part replacement information provided in this article is based on model ADE4BRGS171TW01 and may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What you need

• Replacement heating element (make sure it’s compatible with your specific dryer model before installing)
• 1/4-inch nut driver

Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more:  Troubleshooting Tips for a Dryer Drum That Does Not Turn

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.

Read more: Dryer Making Noise? How to Fix & Troubleshooting

How to replace the heating element

Follow these steps to change out a faulty heating element in your Speed Queen dryer.

Step 1: Access the heating element

1. Unplug the dryer from the power outlet.
2. Use a 1/4-inch nut driver to remove the two screws at the bottom of the front access panel.
3. Use the 1/4-inch nut driver to remove the two screws, one on each bottom corner, on the upper panel of the front of the dryer.
4. Rotate the bottom panel out to about 45 degrees and then move it down.
5. Take a picture of the door switch wiring for later reference.
6. Disconnect the wires for the door switch.
7. Set the panel aside.
8. Remove the four screws holding the front bulkhead to the frame.
9. Lift the bulkhead slightly to clear any tabs, then move it down and out. Set it aside.
10. Remove the belt from the motor.
11. Use the belt to help pull the drum out, then set it aside.
12. Find the heating element at the back left side of the dryer.

Step 2: Install the new heating element

1. Remove the 1/4-inch screws that hold the high-limit thermostat and the thermal fuse to the heating element so they can be moved off the housing.
2. Remove the 1/4-inch screws on the old heating element and move it out of the way.
3. Secure the new heating element in place.
4. Transfer the high-limit thermostat, thermal fuse, and wires from the old element to the new element.

Step 3: Reassemble the dryer

1. Install the drum and belt. Make sure the drum rests securely on the back rollers.
2. Install the front bulkhead and secure it with the 1/4-inch screws.
3. Reconnect the wires to the top front panel, angle it in towards the top panel, and rotate it into place.
4. Secure the bottom of the front panel with the 1/4-inch screws.
5. Hook the bottom front panel back in place and secure it with the final 1/4-inch screws.
6. Plug the dryer back in.
7. Test the dryer to make sure the new heating element works correctly.

Read more: DIY Dryer Troubleshooting: What Is Causing Slow Drying Times?

Looking for more?

Thanks for reading! We hope this guide helped you replace the heating element in your Speed Queen dryer.
