How to change out a faulty terminal block on an electric Whirlpool range

Is your Whirlpool electric range not powering up as it should? A faulty terminal block might be to blame, causing flickering or a complete loss of power. Don’t worry—our step-by-step guide, complete with a helpful how-to video below, will walk you through replacing the terminal block safely and easily, getting your range back in action in no time!

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

The terminal block on an electric Whirlpool range connects the incoming power supply to the internal parts. Over time, regular use and accidental damage can cause the terminal block to become faulty.

Common signs that may indicate the need for terminal block replacement include flickering or intermittent power to the range, burning or melting around the terminal block connections or an inability to get power to the range.

Fortunately, with a few basic tools, a new part and some patience, you can tackle this repair yourself and get your Whirlpool electric range back in working order.

If you need any replacement parts for your Whirlpool range, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Important: The part replacement information provided in this article is based on model WFC340S0AB and may not apply to your specific appliance model. For the most accurate guidance, we recommend consulting the technical sheet for your specific appliance model.

Watch: How To Replace A Whirlpool Electric Range Terminal Block

What you need

• New terminal block  (make sure it’s compatible with your specific range model before installing)
• Phillips head screwdriver

Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more: How to fix an electric Whirlpool range that won’t start after a self-clean cycle

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.

Read more:  How to replace a terminal block on an electric range

How to replace the terminal block

Follow these steps to change out a faulty terminal block on an electric Whirlpool range.

1. Unplug the range from the power source or turn off the circuit breaker to the machine.
2. Use a Phillips head screwdriver to remove the terminal block cover on the back of the range. Set the cover aside.
3. Remove the screws that hold the power cord in place on the terminal block.
4. Note the terminal block orientation and connections before you start disconnecting them. Take a photo so you can refer back to it later on.
5. Disconnect the red, white, and black range wires from the terminal block.
6. Remove the copper ground strap.
7. Remove the screws that hold the old terminal block in place and take it out.
8. Align the new terminal block in the same orientation as the old one and secure it with the mounting screws.
9. Reattach the copper ground strap to the new terminal block.
10. Connect the red, white, and black range wires to the appropriate terminals on the new terminal block.
11. Reinstall the power cord and secure it in place with the screws.
12. Double-check that all the connections are tight and secure.
13. Use the Phillips head screwdriver to replace the terminal block cover.
14. Plug the range back in or turn the circuit breaker back on to restore power.
15. Test the range to make sure the new terminal block is working correctly.

Read more:  Electric Range Element Won’t Heat: Top 7 Reasons & Fixes

Looking for more?

Thanks for reading! We hope this guide helped you replace the terminal block on your Whirlpool electric range.
