How to install LG gas dryer propane orifice 4948EL4002B (natural gas to propane conversion)

Is your gas dryer in need of a conversion but you’re unsure where to start? Switching from natural gas to propane is simpler than you think, thanks to our easy DIY guide. Dive into our step-by-step how-to video below and learn how to safely replace a propane orifice, so you can get your dryer running efficiently in no time!

Need a part?  Search below using your appliance model number to find exactly what you need:

The propane orifice is a crucial part of gas dryers that run on propane fuel. This metering device is mounted on the outlet of the gas valve and regulates the flow of gas to the burners.

If you need to convert your dryer from natural gas to propane, you’ll need to switch out the orifice. The propane orifice has a smaller opening to account for the higher pressure of propane tanks.

You can find a replacement propane orifice here. If you need other replacement parts for your LG dryer, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.

Watch the full repair here!

Read more: 9 Ways To Improve Your Dryer’s Performance

What you need

• Phillips head screwdriver
• Flat blade screwdriver
• Needle-nose pliers
• Short Phillips screwdriver
• 10mm socket wrench
• Pipe thread sealant
• Gloves (optional)
• Container for screws
• New propane orifice (make sure it’s compatible with your specific dryer model before installing)

Read more: Dryer Settings: The Ultimate Guide to Understanding, Using, and Maintaining Your Appliance

Keep safety first

Your safety should always be the top priority when performing any appliance repair.

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by preventing any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Shut off the gas supply to prevent any gas leaks while you work.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can clearly see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.

Read more: Gas Dryer Isn’t Heating: Top 5 Reasons and Fixes

How to install a propane orifice

Follow these steps to replace the propane orifice for your LG dryer:

1. Unplug the dryer from the power outlet.
2. Turn off the gas supply.
3. Remove the three back screws with a Phillips screwdriver so you can slide off the top panel.
4. Remove the steam drawer and container by using a flat-blade screwdriver to release the locking pin.
5. Detach the control board power plug and both wire harness plugs by using a screwdriver to press the locking tabs.
6. Take out the control panel screw.
7. Lift the panel off.
8. Unplug the harness and set it aside.
9. Remove the two front panel screws from the bottom and detach the door switch plug.
10. Tilt the front panel forward and remove it from the hinges. Watch for sharp edges!
11. Disconnect the harness clips with pliers.
12. Take out the five screws to remove the front bracket and disconnect the light plug.
13. Remove the four bulkhead screws plus the one at the bottom.
14. Detach the moisture sensor plug.
15. Lift out the bulkhead and support and tilt the drum as needed.
16. Reach in and push down on the motor pulley to slide it off the belt.
17. Remove the belt.
18. Lift out the drum and set it aside.
19. Remove the igniter screw and carefully detach the igniter, which is very fragile. Be very careful to avoid breaking it!
20. Take out the two screws holding the burner manifold.
21. Use a 10mm socket wrench to unscrew the old orifice. Be gentle and take care to avoid stripping threads!
22. Apply pipe thread sealant to the threads of the new propane orifice.
23. Screw in the new orifice by hand, then use the socket wrench to tighten it the rest of the way. Don’t overtighten!
24. Reinstall the burner manifold and the two screws.
25. Carefully reattach the igniter.
26. Reinstall the drum and thread the belt back into place around the pulleys.
27. Turn the drum by hand fully to make sure it turns smoothly.
28. Position the front bulkhead into place by engaging the hinges and hooks.
29. Reconnect the moisture sensor plug and bulkhead screws.
30. Replace the light plug and front bracket.
31. Reinstall the front panel and switch plug.
32. Reinstall the control panel and harness plugs.
33. Reinstall the steam drawer and top panel.
34. Restore power to the dryer.
35. Turn on the propane supply.
36. Run a test cycle to make sure the igniter is operating correctly and that the burner is firing evenly. Monitor the dryer for several minutes to make sure there aren’t any issues with overheating.
