How to replace GE washer water inlet valve seal WH13X24094

Is your GE washing machine leaving a puddle after every wash? A worn-out water inlet valve seal might be the culprit, but don’t worry—fixing it is easier than you think! Get ready to tackle this leaky problem like a pro with our step-by-step guide and accompanying how-to video just below.

Need a part?  Search below using your appliance model number to find exactly what you need:

If your GE washing machine is leaking water, you might need to replace the water inlet valve seal. Thankfully, this is an easy DIY repair that you should be able to knock out in under an hour.

You can find a replacement water inlet valve seal WH13X24094 here. If you need other replacement parts for your GE washer, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.

Watch the full repair here!

Read more: How to replace the drain pump in a GE washer

What is the water valve seal & why would it need to be replaced?

The water inlet valve seal forms a watertight seal around the water inlet valve. It helps prevent leaks by sealing the connection between the water inlet valve and the washing machine’s internal tubing. Minor leaks can often be fixed by simply swapping out the worn seal.

To do this, you’ll need to access the valve itself, which sits at the back of the machine. With a little patience and the right tools, you can have your GE washer fixed up in no time.

Symptoms of a bad water inlet valve seal include:

• Water leaking from the back or underside of the washing machine
• Visible signs of wear or damage to the seal
• Unexplained increase in water usage or utility bills, which may indicate a slow leak

Read more: GE washer won’t drain: A troubleshooting guide

What you need

• 1/4-inch nut driver
• Small flat-blade screwdriver
• New water inlet valve seal (make sure it’s compatible with your specific washer model before installing)

Read more: How to Deep Clean a Washing Machine

How to replace the water inlet valve seal

Follow these steps to swap out the water inlet valve seal in your GE washing machine.

Step 1: Remove the rear access panel

1. Unplug the washer from the outlet and shut off the water supply.
2. Use a 1/4-inch nut driver to remove the 4 screws that hold the panel.
3. Pull the panel straight out. There are 2 plastic clips at the top that will release as you pull.

Step 2: Disconnect wiring and hoses

1. Insert a small flat-blade screwdriver into the opening on the wiring plug. Push down to unlock it, then pull it out.
2. Remove the ground wire clip.
3. Disconnect the air hose from the control board by pulling it straight down.

Read more: Surprising Things That Can & Can’t Go in the Washer

Step 3: Remove the control panel

Now you can access and remove the main control panel that houses the water inlet valve.

1. Take out the 2 1/4-inch screws along the bottom edge of the panel with a nut driver.
2. Push the panel back slightly to unlock the side clips holding it in place.
3. Carefully turn the panel over and slide it out to the side. Be careful not to stress the wiring harness.

Step 4: Remove the valve

1. Use a nut driver to remove the 3 1/4-inch screws holding the valve.
2. Pull the valve straight out of the machine.

Step 5: Replace the seal

1. Pull out the old, worn seal from the valve port.
2. Press the new seal firmly and completely into the port.

Step 6: Reinstall the valve

1. Carefully align the valve’s screw holes before pressing it back into place on the machine.
2. Use the nut driver to replace the 3 1/4-inch screws to secure the valve.

Read more: 5 Ways To Keep Your Clothes Washer In Great Shape

Step 7: Put the washer back together

1. Place the control panel on top by aligning the side tabs with the slots, then pull it forward to connect it.
2. Use the nut driver to reinstall the two 1/4-inch screws and secure the control panel.
3. Reinstall the air hose onto the control board by sliding it back into place. Make sure it’s fully inserted.
4. Reattach the ground wire clip to the designated spot on the control panel.
5. Flip the washer’s rear cover panel over and align the tabs on the panel with the slots at the top.
6. Use the nut driver to reinstall the four 1/4-inch screws and secure the rear cover panel.
7. Turn on the water supply and plug the washer back into the power outlet.
8. Run a short test cycle to make sure the washer is working correctly.

Read more: What’s A Full Load Of Laundry? A Guide To Efficient Washing

More information

Thank you for reading! We hope this guide helped you get your GE washer working again.
