How to replace the bottom oven door trim WB07X42948 on a GE range

Is your GE oven door trim looking a bit worse for wear? Don’t worry—restoring it to its former glory is easier than you think! Dive into our step-by-step guide below, complete with a handy how-to video, and master the art of replacing your oven door trim like a pro.

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

If your GE oven door trim is damaged or worn out, we’ve got you covered! Let’s walk through the process of replacing the door trim so you can restore your range.

You can find a replacement bottom door trim here. If you need other replacement parts for your GE range, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.

Watch the full repair here

What you need

• Replacement bottom door trim (make sure it’s compatible with your specific oven model before installing)
• Flathead screwdriver
• 1/4-inch nut driver
• Torx 15 screwdriver

Disclaimer: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Safety tips

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• If you have a gas model, shut off the gas supply to prevent any leaks while you work.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.

Read more: 8 DIY Safety Tips

How to replace the bottom oven door trim

Once you’ve got all your materials together, you’re ready to change out the door trim.

Step 1: Remove the oven door

1. Unplug the oven from the electrical outlet.
2. Carefully open the oven door.
3. Use a flathead screwdriver to find and open the hinge locks on both sides of the oven door.
4. Partially close the oven door, then grasp the sides of the door and lift it off the hinges.
5. Place the oven door with the handle side down on a flat, stable surface.

Read more: Why It’s Best to Choose OEM Over Aftermarket Parts for Appliance Repairs

Step 2: Disassemble the door

1. Use a Torx 15 screwdriver to loosen the top screws holding the inner door panel.
2. Use a 1/4-inch nut driver to remove the bottom screws that hold the inner door panel in place.
3. Carefully lift off the inner door panel and set it aside.
4. Note the old trim’s position and orientation for reference later on.
5. Find and remove the screws that hold the old trim to the sides of the oven door, then remove the trim.

Read more: My part is no longer available! What do I do now?

Step 3: Position the new trim

1. Place the oven glass inside the new trim clips.
2. Align the holes on the new trim with the corresponding holes on the oven door.
3. Carefully position the new trim in place and make sure it sits flush against the door.

Step 4: Reassemble the door

1. Insert the screws into the holes on the sides of the oven door and tighten them. Don’t overtighten the screws since doing so may damage the trim or the door.
2. Reattach the inner door panel by aligning it with the screw holes and tightening the screws with the Torx 15 screwdriver.

Read more: Oven Tips for Cooking a Holiday Turkey, Ham & More

Step 5: Reinstall the oven door

1. Hold the oven door at a slight angle and align the hinges with the slots on the oven.
2. Carefully lower the door onto the hinges until it rests in the fully open position.
3. Open and close the door a few times to make sure it works correctly.
4. Lock the hinge locks on both sides of the oven door to secure it in place.
5. Gently close the door to make sure it’s installed and aligned correctly.
6. Plug the oven back in. If you have a gas model, turn the gas supply back on.

Read more: How to Childproof Appliances

More information

Thanks for reading! We hope this guide helped you replace the bottom oven door trim on your GE range.
