How to replace the fabric selector switch on a Speed Queen dryer

The fabric selector switch on your Speed Queen dryer is what its name suggests: it’s used to choose the appropriate drying cycle for your load of laundry. The switch can wear out or become damaged over time, which means you may need to replace it. Some indicators of a bad fabric selector switch may include an unresponsive dryer when the switch is turned, an underperforming dryer during the expected drying cycle or a loose or unresponsive fabric selector switch.

But we have good news for you: you can complete this repair with a few tools, a new part and some patience — no technician required! Let’s get your Speed Queen dryer back in working order.

If you need any replacement parts for your dryer, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Important: The part replacement information provided in this article is based on Speed Queen model ADE4BRGS171TW01 and may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What you need

• Replacement fabric selector switch (make sure it’s compatible with your specific dryer model before installing)
• 1/4-inch nut driver
• Flathead screwdriver

Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more:  How To Disassemble A Dryer

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.

Read more: How to Clean a Dryer Vent

How to replace the fabric selector switch

Follow these steps to replace a faulty fabric selector switch in your Speed Queen dryer.

1. Unplug the dryer from the power outlet.
2. Use a 1/4-inch nut driver to remove the screws that hold the console to the top panel.
3. Rotate the console forward.
4. Use a flat-head screwdriver to lift the locking tab of the fabric selector switch.
5. Rotate the old fabric selector switch and pull it out.
6. Insert the new fabric selector switch into the console and rotate it to lock it in place.
7. Switch the wires over to the new part.
8. Rotate the console back into place and secure it with the 1/4-inch screws.
9. Place the knob onto the new timer.
10. Plug the dryer back into the power outlet.

Read more: How To Replace A Dryer Door Switch

Additional information

Thanks for reading! We hope this guide helped you replace the fabric selector switch on your Speed Queen dryer.
