How to replace ice maker WPW10300022 on a Whirlpool refrigerator

Is your refrigerator’s ice maker on the fritz, leaving you with warm drinks and frustration? Don’t worry—our handy guide is here to help you replace the troublesome Whirlpool ice maker assembly and restore your ice supply in no time. Check out the how-to video below to tackle this repair confidently and keep your appliances running smoothly!

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

The ice maker assembly is responsible for producing ice in your refrigerator. Over time, it may stop making ice or make very little. You may also see debris in the ice from the ice mold coating being damaged. In such cases, replacing the ice maker assembly can resolve the problem.

This repair is relatively easy and should only take a few minutes to complete. By following the step-by-step instructions provided in this guide, you can save time and money by performing the replacement yourself, without the need for professional assistance. With some basic household tools you’ll be able to successfully replace the ice maker assembly and have your refrigerator producing ice like new again. Let’s get started!

Watch here: How To: Whirlpool/KitchenAid/Maytag Icemaker Assembly WPW10300022

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

What you’ll need

• Phillips screwdriver
• Flathead screwdriver
• 1/4″ nut driver

Safety precautions

• Always power off and unplug your appliance or switch off the circuit breaker before attempting any maintenance or replacement work. This keeps you safe by preventing any risk of injury from electric shock.
• Don’t test wiring with a multimeter for live voltage if you’re unfamiliar with how to prevent short circuiting when testing.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access the interior parts.
• Clear your workspace of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with bare wet hands. Make sure the work area is completely dry.
• Check your user manual to see if there are specific installation or safety instructions for your part or appliance.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause injury.
• Wear insulated work gloves to protect your hands from sharp metal parts, pinching hazards and debris.
• Wear safety glasses when working with chemicals, dust or cleaning large debris to prevent injury.

Replacement steps

1. Open the freezer door and pull out the ice bin.
2. Use the Philips screwdriver to unscrew the rear screw of the ice maker assembly.
3. Loosen up the front screw of the ice maker assembly using the Philips screwdriver and drop the rail down.
4. Use the flathead screwdriver to pry open and remove the ice maker head cover.
5. Use the nut driver to loosen up the two mounting screws on the top of the ice maker assembly.
6. Raise the ice maker arm and remove the 1/4 inch screw at the bottom of the ice maker assembly.
7. Lift up and remove the old ice maker assembly from the wall.
8. Turn the old ice maker assembly sideways and use the flat blade screwdriver to push the tab and remove the wire plug from the ice maker.
9. Disconnect the wire plug inside the freezer. Take the old ice maker assembly to a worktable.
10. Use the flat blade screwdriver to pry out the ice maker arm and remove it from the water cup. Set it aside as it will be reused.
11. Turn the old ice maker assembly over and use the nut driver to remove the three screws and detach the base.
12. Secure the base of the new ice maker assembly with the three screws using the nut driver.
13. Place the ice maker arm under the new ice maker assembly, inserting one end into the opening in the ice maker’s head and the other end into the hole in the water cup.
14. Bring the new ice maker assembly into the freezer and place it on the side.
15. Connect the wire plug to the new ice maker assembly, sliding it into the wire plug at the rear.
16. Slide the ice maker cup onto the inlet tube and then hang the ice maker assembly on the two screws in the freezer.
17. Tighten the screws with a quarter inch nut driver to secure the ice maker assembly in place.
18. Make sure that the ice maker water inlet tube is inside the cup.
19. Install the bottom screw of the ice maker assembly.
20. Close down the ice maker arm.
21. Reattach the rail and secure it with the two screws using the Philips screwdriver.
22. Slide the ice bin back into place in the freezer.
23. Close the freezer door. Plug the fridge back in and check that it cools down.

Additional information

Thanks for reading! We hope this guide helped you replace the ice maker assembly on your Whirlpool refrigerator.
