How to replace the start device on a Frigidaire refrigerator that’s not cooling (compressor not running)
Steven E / Thursday June 20, 2024
On a Frigidaire refrigerator, the compressor start device provides the initial electrical surge needed to start the compressor so your refrigerator can begin removing heat from the interior. Over time, the compressor start device may fail or become damaged.
If the compressor fails to start, the refrigerator isn’t cooling properly, or the compressor is making unusual noises, then you’ll most likely need to change out the start device.
And the good news: With a few basic tools and some patience, you can tackle this repair yourself and get your Frigidaire refrigerator back in working order.
You can find a replacement Frigidaire compressor start kit here. If you need other replacement parts for your Frigidaire refrigerator, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.
Important: The part replacement information provided in this article may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.
What you need
- Replacement compressor start kit (make sure it’s compatible with your specific refrigerator model before installing)
- 1/4-inch nut driver
- Multimeter
Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.
Read more: How To Deep Clean Your Refrigerator
Safety tips
When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:
- Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
- If the appliance has recently been used, give it plenty of time to cool down before working on it.
- Turn off the water supply at the outlet before beginning repairs. Keep towels ready to catch any residual water in the system when removing parts.
- Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
- Work in a well-lit area so you can see and access appliance parts.
- Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
- Never work on internal parts with wet hands. Make sure the work area is completely dry.
- Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
- Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
- Wear insulated work gloves to protect your hands from sharp metal parts and debris.
- When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
- Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.
Read more: How To Replace A Refrigerator Compressor Start Relay
How to replace the start device
Follow these steps to swap out the start device on your Frigidaire refrigerator.
- Slide the refrigerator out from the wall.
- Disconnect the refrigerator power cord from the wall outlet and shut off the water supply.
- Use a 1/4-inch nut driver to remove the four screws holding the rear access cover in place.
- Find the compressor on the left side of the refrigerator. The start device will be mounted on the side of the compressor.
- Remove the wire clip that secures the start device.
- Disconnect the start device wiring.
- Connect the wiring to the new start device.
- Align the pins on the compressor with the holes on the new start device and slide it into place.
- Reconnect the wire clip to secure the start device.
- Replace the rear access cover and reinstall the four screws.
- Plug the refrigerator back in and turn the water supply back on.
- Test the fridge to make sure it starts up correctly and begins cooling.
Additional information
Thanks for reading! We hope this guide helped you replace the start device on your Frigidaire refrigerator.
