Replace Whirlpool washer motor rotor W10754161: A complete guide

Is your Whirlpool washer refusing to spin or making unsettling noises during the spin cycle? The culprit could be a faulty motor rotor, a common issue that can disrupt your laundry routine. Don’t worry, though—our easy-to-follow guide below includes a step-by-step how-to video that will turn you into a DIY repair expert in no time!

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

If your Whirlpool washer won’t spin or is making loud noises during the spin cycle, then you might have a faulty motor rotor. The motor rotor is what allows the inner tub to spin during the wash and rinse cycles. Over time, it can become damaged from normal wear and tear.

Fortunately, replacing the motor rotor is a straightforward process that you can complete yourself to save time and money.

You can find a replacement motor rotor here. If you need other replacement parts for your Whirlpool washer, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.

Watch: How to install washer motor rotor

An overview of how a washing machine motor works

The motor on a washing machine has two main parts: the stator and the rotor. The stator is the stationary portion, typically mounted to the exterior housing of the gearcase. The rotor covers the stator and rotates to drive the internal basket.

Powerful magnets mounted inside the rotor interact with the electromagnetic field that’s produced by the stator. This interaction causes the rotor to spin very quickly, up to 1600 RPM on some washers. The rotor connects to the inner tub via a shaft in the center and transfers the spinning motion to agitate and rinse the clothing.

Over time, the rotor magnets can lose their strength. The splines that connect the rotor to the drive shaft may also become damaged or cracked. Any of these issues can lead to problems with the spin cycle.

Read more: Why It’s Best to Choose OEM Over Aftermarket Parts for Appliance Repairs

Signs of a faulty motor rotor

There are a few signs that indicate the rotor needs to be replaced:

• No spin or agitation – If the tub sits motionless when you expect it to spin, the rotor is likely the issue if the stator and motor control board are still functioning properly.
• Loud noises – Grinding or rattling sounds coming from the motor during the spin cycle often mean the rotor magnets are worn out. The splines may also be damaged.
• Burning smell – If you notice a burning odor and the tub won’t spin, but the motor is still humming, this indicates an electrical short. The stator likely needs to be replaced.

Read more: My part is no longer available! What do I do now?

What you need

• Replacement motor rotor  (make sure it’s compatible with your specific dryer model before installing)
• Torx 30 socket wrench
• Plastic mallet

Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more: 6 Easy Ways to Perk Up Your Laundry Room

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Turn off the water supply at the outlet before beginning repairs. Keep towels ready to catch any residual water in the system when removing parts.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.

How to replace the motor rotor

Change out the motor rotor by following these steps.

1. Unplug the washer and turn off the water supply line.
2. Flip the washer onto its front side and place it on a sturdy surface for support. You may need the assistance of another person to complete this step.
3. Remove the installation pad covering at the bottom of the washer by bending it up at the edges and pulling it off.
4. Access the motor rotor under the center of the washer. It’s attached by a central mounting bolt.

Pro tip: Penetrating oil or WD-40 can help loosen a stuck rotor bolt. Allow it to soak in for a few minutes before trying to remove it.

5. Use a torque wrench with the appropriate socket size to loosen the mounting bolt. You may need to use a plastic mallet to tap the wrench if the bolt is stuck.
6. Unscrew and fully remove the mounting bolt to detach the motor rotor. Be careful while handling it as it contains strong magnets.
7. Shake or slide the old motor rotor side to side to fully remove it from the shaft.
8. Take the new replacement motor rotor and align the internal splines to the shaft splines before sliding it into place. Watch for fingers near the magnets.
9. Replace the mounting bolt and tighten it with the torque wrench. Apply additional force with the plastic mallet if needed. Don’t overtighten the bolt – if you do, you could strip the threads.
10. Replace the installation pad cover.
11. Return the washer to the upright position.
12. Plug the power cord back in and turn on the water supply.
13. Review the included instructions for the new motor rotor and recalibrate the washer as specified.
14. Run a small test cycle to check for any leaks or issues with spinning.

Read more: Tips For Preventing Laundry Damage in Your Washing Machine

Looking for more?

Thanks for reading! We hope this guide helped you replace the motor rotor in your Whirlpool washer.
