Troubleshooting GE refrigerator error code F507

Is your GE refrigerator displaying error code F507? Don’t worry, this is a problem that you can fix yourself without the need for a costly service call and we’re here to help you do it!

If you find out that you need any replacement parts for your appliance while you’re troubleshooting, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Important: The error code information provided in this article may not apply to your specific appliance model. The disassembly information is based on GE models Adora, Cafe, and Profile french door refrigerators from 2014-2015. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What the error code means

This error code indicates an issue with the cold water dispenser paddle switch on the refrigerator. The control system is detecting that the input from the paddle switch is missing or not being registered correctly. The paddle switch is responsible for detecting when the water dispenser paddle is pressed and signaling the control board to activate the water dispenser.

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before attempting any maintenance or replacement work. This keeps you safe by preventing any risk of injury from electric shock.
• Wear insulated work gloves to protect your hands from sharp metal parts, pinching hazards and debris.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access the interior parts.
• Clear your workspace of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with bare wet hands. Make sure the work area is completely dry.
• Check your user manual to see if there are specific installation or safety instructions for your part or appliance.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause injury.
• Wear safety glasses when working with chemicals, dust or cleaning large debris to prevent injury.
• If the appliance has recently been used, give it plenty of time for any heating parts to cool down before working on it.
• Take pictures or make a note of wiring terminals or other connections before disconnecting to prevent any problems with reassembly.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Turn off the water supply at the outlet before beginning repairs to any appliance parts that hold water. Have towels ready for any residual water in the system when removing parts.

Read more: Refrigerator Won’t Dispense Water: Top 6 Reasons and Fixes for Kenmore, Whirlpool, Frigidaire, GE, and Other Brands

Tools and materials needed

• 1/4”, 5/16” and 3/8” Nut drivers, sockets or wrenches
• T15, T20 and T27Torx bits
• Flathead screwdriver
• Phillips screwdriver
• Multimeter

Important: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more: How to clean and maintain your refrigerator’s water dispenser

Troubleshooting steps

Access the switch

The paddle and switch are attached to the dispenser recess with two top pins and two bottom tabs. The paddle and switch are a complete assembly and cannot be replaced separately.

1. Unplug the refrigerator from the outlet.
2. Pull the bottom of the display assembly out, then lower the display assembly from the dispenser recess.
3. Disconnect the left side wire harnesses and lift and pivot open the metal shield.
4. Disconnect the speaker wire, two upper sensors, and the lower harnesses.
5. Disconnect the shield wire from the metal shield.
6. Remove the six T-15 Torx screws that attach the display board to the display cover bracket.
7. Pull the fill tube out from the funnel.
8. Disconnect the duct door motor wire harness and remove the motor wiring from the wire
9. retainers.
10. Push up on both the right and left retainers and pull the funnel out from the dispenser recess.
11. Note: The funnel on some models is attached to the dispenser recess with two 1/4 in. hex head screws.
12. Make a note of the position of the duct door return spring before removing.
13. Using a flat blade screwdriver, gently pry the duct door motor out from the motor bracket.
14. Disconnect the actuator switch wire harness.
15. Using a small flat blade screwdriver, gently pry inward and disengage each top pin from the dispenser recess and then pull the paddle up.

Test the switch

1. Locate the three wires connected to the paddle switch. These wires will be colored differently, typically red, white, and black, however this may vary depending on your model.
2. Set your multimeter to the resistance (Ω) setting.
3. With the paddle switch in the normal (no water dispensed) position, use the multimeter to check the resistance between the terminals.
4. Between the red and white wires you should see a closed circuit (0 Ω resistance).
5. Between the red and black wires you should see an open circuit (infinite resistance).
6. Gently press the paddle switch to the dispense position (fully pushed in) and check the resistance between the same terminals.
7. Between the red and white wires you should see an open circuit (infinite resistance).
8. Between the red and black wires you should see a closed circuit (0 Ω resistance).
9. If the resistance readings do not match the expected values in both the normal and dispense positions, the paddle switch is faulty and will need to be replaced.
10. If the paddle switch is functioning correctly, check the wiring between the switch and the refrigerator’s control board for any damage, loose connections, or shorts.
11. If the wiring appears to be in good condition, the issue will be with the control board and you will need to replace it.
