Why is your water heater overflow pipe dripping? Causes & easy fixes

Noticed your water heater’s overflow pipe dripping lately? It might seem like a minor issue, but that little drip could be telling you something about what’s going on inside your water heater. Don’t worry, though, there are usually some pretty simple reasons why it’s happening, and even easier fixes to get things back to normal.

If you need any replacement parts for your appliances, you can enter your model number at AppliancePartsPros.com to order them. Most orders arrive in just two business days, and we have thousands of free guides to show you how to install your new parts.

Important: The information provided in this article may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What is the water heater overflow valve?

The water heater overflow valve, commonly known as the temperature and pressure (T&P) relief valve, is part of a safety system. It prevents your water heater from becoming over-pressurized by releasing excess water when the temperature or pressure inside the tank reaches unsafe levels. When the T&P valve opens, water is directed through the water heater overflow pipe to drain away safely.

If your water heater overflow pipe is dripping, it’s a sign that the T&P valve is actively releasing water, which could indicate a problem with the valve, the tank, or the plumbing system itself.

Common causes of a leak from the overflow pipe

Excessive water pressure

If your home’s water pressure is too high, the T&P valve may open frequently, causing water to escape through the overflow pipe. High water pressure within the tank creates stress, prompting the valve to release water as a safety measure. This is one of the most frequent reasons for a water heater overflow pipe dripping.

Malfunctioning temperature and pressure relief valve

A faulty T&P valve can cause unnecessary leaks, even when pressure and temperature levels are within the normal range. Over time, the valve may wear out, corrode, or become clogged with sediment, resulting in a water heater leaking from the overflow pipe.

Thermal expansion and overheating

When water heats up, it expands. If your water heater’s thermostat is set too high, it can cause the water to overheat, resulting in pressure buildup inside the tank. Without an expansion tank to relieve this extra pressure, the T&P valve will release water, leading to a hot water heater leaking from the overflow pipe.

No expansion tank installed

If your water heater system doesn’t have an expansion tank, there’s nowhere for the extra water to go when it expands during heating. This can lead to increased pressure in the tank, causing the T&P valve to discharge water to reduce the pressure.

How to troubleshoot

If you’re dealing with a water heater leaking from the overflow pipe, follow these troubleshooting steps to pinpoint and resolve the problem:

Step 1: Check your water pressure

1. Test the water pressure in your home using a pressure gauge, which can be purchased at most hardware or home improvement stores.
2. Locate a water outlet in your home, such as an outdoor faucet or a washing machine connection, where you can attach the pressure gauge.
3. Turn off all water appliances and faucets in your home to get an accurate reading.
4. Attach the pressure gauge to the chosen water outlet and open the valve slowly to allow water to flow into the gauge.
5. Read the pressure displayed on the gauge. If the pressure exceeds 80 psi (pounds per square inch), it is considered high and could be the cause of the water heater overflow.

Step 2: Inspect the temperature and pressure relief valve

1. The pressure relief valve is typically located near the top of the water heater. It is usually recognizable by a long pipe extending down from it, which serves as the overflow pipe.
2. Before inspecting, turn off the power supply to the water heater to prevent any accidents or injuries while handling the valve.
3. Place a container or bucket below the overflow pipe of the pressure relief valve to catch any water that may be released.
4. Carefully lift the lever on the pressure relief valve slightly to release some water. Be cautious as the water may be hot.
5. Watch for the water flow from the overflow pipe. If water continues to drip from the pipe after releasing the lever and does not stop, it indicates that the valve is not functioning correctly.
6. If water doesn’t flow from the pipe when you lift the lever, or if it stops flowing when you release the lever, the valve may be stuck and needs to be replaced.
7. After releasing the lever and allowing some water to flow out, the pressure relief valve should reseal itself properly. If the valve continues to leak water after resealing, it is a sign that the valve is faulty and requires replacement.
8. Check the pressure relief valve for any signs of corrosion, mineral buildup, or damage. If the valve appears corroded or shows signs of wear, it is recommended to replace it.

Step 3: Adjust the thermostat

Check the temperature settings on your water heater. If the thermostat is set too high (above 120°F), the water may be overheating and expanding, causing the T&P valve to release water.

1. The temperature controls are typically found on the front of the unit near the bottom or on the side of the tank. Some may have a dial or digital controls.
2. Verify the current temperature setting on the water heater. The recommended temperature setting for most households is between 120 to 140 degrees Fahrenheit (49 to 60 degrees Celsius).
3. For water heaters with a dial: Turn the dial towards the lower temperature setting to reduce the temperature.
4. For water heaters with digital controls: Use the control panel to lower the temperature setting to the desired level.
5. After adjusting the temperature setting, allow some time for the water heater to stabilize at the new temperature. Monitor to see if the dripping from the overflow pipe stops.
6. Make sure to follow the manufacturer’s instructions and safety guidelines to prevent accidents.

Step 4: Inspect the tank for buildup

If you notice sediment buildup in the drained water or suspect that there is sediment accumulation in the tank, consider flushing the tank to remove the sediment. Here’s how you can flush the tank:

1. Turn off the water heater and let it cool down. For gas heaters, set the gas control valve to the “pilot” position.
2. Locate the drain valve on the tank. It is typically located near the bottom and looks like a hose bib with a threaded end.
3. Attach a garden hose to the valve and run it to a drain, utility sink, or outside.
4. Open a hot water faucet in your home to allow air into the system and help with drainage.
5. Open the valve and allow the tank to drain completely. Be cautious as the water can be hot.
6. To further flush the tank, turn the cold water supply back on for a few minutes while the drain valve is still open. This helps to flush out any remaining sediment that may be settled at the bottom of the tank.
7. Once the water runs clear and you have flushed the tank adequately, close the drain valve by turning it clockwise.
8. Disconnect the hose from the drain valve.
9. Turn on the water supply to refill the tank. Keep the hot water faucet open to release any air trapped in the system.
10. For electric heaters, switch the power back on at the breaker box. For gas heaters, set the gas control valve back to the desired temperature.

Step 5: Install an expansion tank

1. Choose an expansion tank that matches the water heater’s capacity and pressure specifications. Refer to the manufacturer’s guidelines for compatibility.
2. Turn off the power supply to an electric water heater or set the gas control valve to the “pilot” position for a gas water heater. Shut off the main water supply to the house.
3. Connect a garden hose to the drain valve at the base of the water heater and drain a few gallons of water to relieve pressure.
4. Install the expansion tank on the cold water supply line near the water heater.
5. Position the tank vertically with the air valve facing upwards.
6. Cut the cold water supply line and solder a tee fitting into the line.
7. Connect the expansion tank to the tee fitting. Ensure the tank’s inlet is connected to the cold water line and the outlet to the water heater.
8. Use pipe straps to secure the expansion tank to the wall or a nearby support structure.
9. Use a tire pressure gauge to check the air pressure in the expansion tank. It should match the water pressure in the plumbing system, typically around 50-60 psi (pounds per square inch).
10. Turn on the main water supply and check for any leaks around the expansion tank and fittings.
11. Once the expansion tank is installed and there are no leaks, restore power to the water heater and turn on the gas supply if applicable.

People also ask

Why is my water heater overflow pipe dripping?

A water heater overflow pipe dripping is usually caused by excessive pressure or temperature inside the tank. The temperature and pressure relief (T&P) valve is designed to open when the pressure or temperature exceeds safe levels. If the T&P valve opens frequently, it’s typically a sign of high water pressure, overheating, or a malfunctioning valve.

How do I stop my water heater from leaking from the overflow pipe?

To stop your water heater leaking from the overflow pipe, follow these steps:

1. Check the water pressure in your home using a pressure gauge. If it’s too high (above 80 psi), install a pressure reducing valve.
2. Inspect the T&P valve for signs of corrosion or damage. If faulty, replace the valve.
3. Lower the water heater’s thermostat if the temperature is set too high (above 120°F), as overheating can cause pressure buildup.
4. Consider installing an expansion tank to relieve pressure caused by thermal expansion.

Is it normal for a water heater overflow valve to leak?

No, it’s not normal for the water heater overflow valve to leak continuously. The valve should only release water in rare cases when the temperature or pressure becomes too high. A constant leak should be addressed promptly to prevent further damage.

Why is my hot water heater leaking from the overflow pipe but not my cold water?

If your hot water heater is leaking from the overflow pipe, but the cold water system is fine, the issue likely lies within the water heater. The T&P valve could be releasing water due to pressure buildup caused by overheating or high pressure in the hot water tank. It’s a safety mechanism that prevents damage to the water heater.

Can I fix the water heater overflow leak myself?

Yes, you can often fix a water heater overflow leaking issue yourself by:

1. Checking the water pressure
2. Inspecting and replacing the T&P valve if it’s faulty.
3. Adjusting the thermostat to prevent overheating.
4. Installing an expansion tank if thermal expansion is causing excess pressure.
