Parts for Ge UCG1600LBB: Motor & Drive Parts

This slotted spring pin is a small retaining fastener that secures shafts, levers, and small assemblies so moving parts stay aligned and engaged. It restores proper mechanical retention in controls and linkages. What it does:

• Holds shafts, levers, and linkage components in place to prevent unintended movement or disengagement
• Keeps control knobs, actuator arms, and small rotating parts secured under normal operation
• Commonly replaced when the original pin is worn, bent, broken, or missing
• Helps eliminate symptoms like loose or disconnected knobs, slipping linkages, or intermittent mechanical engagement

• One spring slotted pin (single)

• Disconnect power (and water if applicable) to the appliance before servicing
• Remove the damaged pin and install the replacement using appropriate pliers or a pin punch; do not force metal parts
• Verify correct orientation and full engagement of the pin in the retaining hole before reassembling
• If the pin is difficult to seat, inspect mating parts for wear or distortion and replace any damaged components

This wave washer is a small metal spring-style washer that cushions and spaces rotating components to reduce vibration and maintain proper alignment. It helps restore smooth operation and prevents excess wear on adjacent parts. What it does:

• Acts as a spring spacer to maintain correct clearance between moving parts
• Absorbs minor vibration and shock to reduce noise during operation
• Helps keep shafts, pulleys, or seals aligned for proper function
• Worn or missing washers can cause noise, uneven spinning, or premature wear

• Disconnect power and water before servicing the appliance
• Inspect mating parts (shafts, pulleys, seals) and replace any damaged components
• Install with the correct orientation and seating; do not force or deform the washer
• Use the exact replacement part number for proper fit and function

A Teflon washer that provides a low-friction, wear-resistant bearing surface to protect mating parts and reduce noise from rubbing or binding. Ideal when a worn washer causes rough movement or squeaks. What it does:

• Provides a smooth, low-friction surface between moving or fastened parts
• Protects metal components from abrasive wear and galling
• Helps reduce noise such as squeaking or grinding from rubbing parts
• Maintains alignment and spacing where a thin, durable washer is required

• Replace only with the exact part number to ensure proper fit and function
• Inspect mating surfaces and fasteners for wear; clean before installing the new washer
• Hand-start fasteners to avoid cross-threading; tighten to the appliance manufacturer's recommended torque

This clip ring is a small retaining clip that secures shafts, hoses, or components in place to prevent movement or separation during operation. It provides a simple, durable hold to keep parts aligned and stable. What it does:

• Holds a shaft, hose, or assembly in position to prevent slipping or disengagement
• Keeps connected parts aligned to reduce vibration and wear
• Helps maintain seals and connections that can otherwise leak or come loose
• Commonly needed when a clip is broken, bent, or missing

• Disconnect power and water before beginning any repair
• Confirm correct orientation and seating before restoring operation
• Use appropriate hand tools (needle-nose pliers or retaining-clip tool) and avoid excessive force
• Replace any damaged fasteners or adjacent parts; do not reuse a deformed clip
