Bosch Gas Range Igniter Mounting Clip 00189322 Guide

Is your Bosch gas burner refusing to ignite, leaving you frustrated at mealtime? The culprit might be a misaligned igniter due to a faulty mounting clip. Luckily, replacing it is a quick DIY solution, and you can watch our step-by-step video guide below to spark your stove back to life with ease.

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

If your Bosch gas burner isn’t lighting properly or the igniter looks loose or off-center, the mounting clip (part #00189322) might be the issue. This tiny but essential part keeps the igniter properly aligned for consistent burner ignition. Fortunately, replacing it is a quick and easy DIY fix. We’ll show you how to remove the faulty clip and install a new one so your gas range sparks up every time.

Watch: How to replace igniter mounting clips

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

Necessary Materials and Tools

Gather the following equipment before starting this repair:

• Igniter mounting clip – This is the key part you’ll be replacing. For the Thermidor ranges, the manufacturer’s part number is 00189322. Use your model number to locate the correct part for your unit.
• Flathead screwdriver
• 13/16” socket wrench
• Towel
• Gloves

Shut Off Power to the Range

Before any major appliance repair, always disconnect the power first as a safety precaution. There are two ways to do this:

• Unplug the range from the electrical outlet.
• Locate the circuit breaker box and flip the switch controlling the range circuit to OFF.

With the power cut-off, you can now safely work on the range’s internal parts without the risk of dangerous electric shocks.

Remove the Grates and Burner Caps

Start by removing all grates from the top of the cooktop. Lift them straight up and set them aside so they won’t get damaged.

Next, remove the burner caps. These are the outer rings situated on top of each burner base. Grasp the caps one by one and gently pull them up and off the burners. Take care not to bend or warp them during removal.

With the grates and burner caps out of the way, you’ll have clear access to disassemble the cooktop components.

Detach the Burner Bases

The burner bases are held in place by securing nuts underneath the cooktop. Use a 13/16” socket wrench to loosen and remove the nuts from each base.

Turn the wrench counter-clockwise to loosen the nuts. Once loosened, the bases should lift up and detach easily. Remove all four burner bases and set them aside with the other components.

Tip: Sometimes these nuts become stubbornly stuck over time. If the wrench alone doesn’t work, use a blow torch to heat them up and break them loose.

Pull Out the Cooktop

With all burners removed, you can now pull out the cooktop to access the underside where the igniter mounting clips are located.

Place a towel on the back of the range first. This prevents the cooktop from getting scratched or damaged as you pull it out.

Gently pull the cooktop forward, making sure any wiring or connectors have enough slack and are not strained. Once pulled out, rest the cooktop on top of the towel.

Remove the Old Igniter Clip

Examine the underside of the cooktop to locate the igniter mounting clip. It’s a small rectangular plastic piece with a slot on one side.

Take your flathead screwdriver and insert the tip into the slot on the clip. Gently pry it towards you, working it loose from the bracket. As you pry, the old igniter clip will pop off the igniter plug. Remove it completely.

Thoroughly inspect the area and make sure no part of the old clip remains stuck. Use a flashlight to see better if needed.

Install the New Igniter Clip

Once the old igniter clip is fully removed, you can install the new replacement clip.

Orient the new clip correctly, with the slit side facing out. Push the igniter plug from the back side so the tip pokes through as you simultaneously slide the new clip into position over it. Use the flathead screwdriver to guide the clip onto the bracket if needed.

Make sure the clip seats flush and securely into the retaining notch. Give it a few tugs with your hand to verify it’s locked on tight. If there’s any looseness, remove and reinstall until properly seated.

Caution: Do not bend or damage the delicate igniter tip during this process.

Reattach the Burner Bases

With the new igniter mounting clip installed, you can begin reassembling the cooktop components.

Replace each of the 4 burner bases by lowering them down into position. These are keyed so pay attention to proper alignment – one side of the base will have a notch cut out which fits around the igniter tip.

Once aligned, replace the mounting nuts underneath using the 13/16” socket wrench. Tighten them down securely but do not over-tighten.

Replace Burner Caps and Grates

The burner bases are now solidly refastened. Place the burner caps back onto each base by aligning and pressing down gently.

Finally, position the grates back on top of the cooktop in their original locations.

Take care not to scrape or scratch the cooktop surface when lowering the grates into place.

Reconnect Power and Test

With everything put back together, it’s time to plug the range back in or flip the circuit breaker switch back on.

Thoroughly test each burner, activating the igniters and checking flame strength and consistency. The fresh igniter mounting clips will help stabilize the igniter tips for optimal performance.

If any burner fails to ignite or has low flames, double-check the alignment of components and make sure everything is tight. With properly seated new clips, the burners should light reliably.

Be very cautious when testing – do not leave burners unattended with the gas on. Shut them off promptly if the operation seems abnormal.
