How to replace a leaf blower recoil starter

Can’t get your gas-powered leaf blower to fire up? A finicky pull-start can be a real headache, but maybe all it needs is a new recoil starter. Let me walk you through how to get that pull-start working like it should.

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

What is the recoil starter?

The recoil starter on a leaf blower is a manual pull-start mechanism that allows the engine to start. It consists of a cord, pulley, return spring, and housing. When you pull the starter cord, it engages the engine’s crankshaft, spinning it fast enough to ignite the fuel and air mixture in the combustion chamber. Once the engine starts, the return spring pulls the cord back into place.

Before you get started: safety first!

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• If working indoors, make sure there is adequate ventilation to prevent the buildup of exhaust fumes. Carbon monoxide poisoning can be a serious risk.
• Wear insulated work gloves to protect your hands from sharp metal parts, pinching hazards and debris.
• Never attempt to service or repair while it is running or when the engine is still warm. Wait for all moving parts to come to a complete stop.
• Exercise extreme caution when working near blades, augers, or any other moving parts. Keep your hands, fingers, and clothing clear of these areas at all times.
• If the appliance has recently been used, give it plenty of time for any hot parts to cool down before working on it.
• Empty the gas tank before beginning any work. Refill using fresh fuel.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access the interior parts.
• Clear your workspace of clutter and other obstacles. Keep children and pets away from the work area.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause injury.
• Wear safety glasses when working with chemicals, dust or cleaning large debris to prevent injury.
• When not in use, store the machine in a safe and dry location.

What you need

Grab these tools and parts to make the job smoother:

• A new recoil starter assembly that fits your leaf blower model.
• A Torx driver or the right screwdriver to remove screws.
• Work gloves to keep your hands safe.

If you’re scratching your head about your blower’s model number, check out our guide on finding your appliance’s model number.

Step-by-step: replacing the recoil starter

1. Take off the recoil starter

First up, find the recoil starter housing—usually held on with screws.

1. Use your Torx driver to remove the screws holding the starter housing in place.
2. Carefully lift off the housing to get to the recoil starter assembly.

2. Remove the old starter

With the housing out of the way:

1. Unwind any leftover starter rope from the pulley.
2. Check out the starter spring and other bits for any damage.
3. Take out any screws or clips holding the recoil starter.

3. Install the new starter

Time to get the new one in there.

1. Line up the new recoil starter with the mounting holes on the engine housing.
2. Screw it in using the screws you set aside earlier.
3. Make sure the starter pulley spins smoothly and the spring’s sitting right.

4. Put the starter housing back on

Almost there!

1. Place the starter housing back over the recoil assembly.
2. Tighten up the housing screws.

5. Give it a test run

Before you call it a day:

1. Reconnect the spark plug.
2. Pull the starter rope a few times to make sure it’s retracting nicely.
3. Fire up the leaf blower to see if everything’s running smoothly.

Handy tips for success

Winding the starter spring correctly

One tricky part can be winding the starter spring. If it’s not set up correctly, it might not have enough tension or could unwind.

1. When you’re putting in the new starter, make sure the spring’s wound tight.
2. Keep a firm grip on the spring as you attach the pulley.
3. Double-check that the spring catches the pulley teeth.

Watch out for model differences

Remember, leaf blowers can vary a lot between models. So:

• Check your manufacturer’s instructions for any special steps.
• Look up model-specific videos on YouTube for a visual guide.
• Make sure you’re using parts that fit your exact model.

Need help finding the right parts? Swing by our repair help section.

Running into problems?

Starter rope won’t snap back

If the rope isn’t retracting after the swap:

• Check that the spring’s installed right and didn’t slip.
• Make sure the rope isn’t tangled or caught on something inside.

Blower still won’t start

If it’s still giving you trouble:

• Make sure there’s fresh fuel in the tank.
• Confirm the on/off switch is set correctly.
• Look at the air filter—if it’s dirty or blocked, clean or replace it.
• Inspect the spark plug for wear or damage and replace it if needed.
• Check the fuel lines and carburetor for any clogs.
