How to replace center shaft o-ring WP67500-55 on a KitchenAid stand mixer

Is your KitchenAid stand mixer underperforming due to leaks or reduced rotation? It might be time to replace the center shaft o-ring, a common issue that’s easier to fix than you might think. Dive into our step-by-step guide below, complete with a handy how-to video, and bring your mixer back to peak performance in no time!

Need a part?  Search below using your appliance model number to find exactly what you need:

The center shaft o-ring on a KitchenAid stand mixer helps maintain a watertight seal between the machine’s center shaft and planetary assembly. It’s situated within the mixer’s head and keeps debris from getting inside. Over time, this o-ring may wear out, which can lead to leaks or reduce the mixer’s ability to rotate.

But we have great news for you: Replacing the center shaft o-ring is a relatively easy repair that can be done all by yourself, with a few basic tools and tips.

Let’s unpack how you can restore your KitchenAid stand mixer.

You can find a replacement center shaft o-ring WP67500-55 here. If you need other replacement parts for your KitchenAid stand mixer, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.

Watch here: How To: Whirlpool/KitchenAid/Maytag Center Shaft O-Ring WP67500-55

What you’ll need

• Flathead screwdriver
• Hammer
• Punch
• Small Phillips screwdriver
• Rubber mallet
• New center shaft o-ring (make sure it’s compatible with your specific model before installing)

Disclaimer: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more:  How to replace a KitchenAid stand mixer power cord

Check part compatibility

Before you replace the center shaft o-ring, make sure you have an OEM part that’s compatible with your specific mixer model. To do this, you’ll need to find the appliance model number.

The model number will say MOD or Model before the numbers and is typically found on a sticker or a metal plate in one of the following locations:

• On the underside of the mixer’s base
• On the back of the mixer’s head or motor housing
• On the side of the mixer’s base

Once you’ve found the model number, write it down or take a clear photo of it for reference.

Next, visit AppliancePartsPros.com, where you can enter your model number to check if the replacement center shaft o-ring is compatible with your model.

Read more:  KitchenAid Stand Mixer Attachments To Try

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by preventing any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can clearly see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.

How to replace the center shaft o-ring

Follow these steps to swap out the center shaft o-ring in your KitchenAid stand mixer.

Step 1: Remove the old center shaft o-ring

1. Unplug the mixer from the power outlet.
2. Remove the beater by lifting it and turning it clockwise. Set it aside once it’s out of the mixer.
3. Remove the bowl by lifting it and pulling it out. Set it aside.
4. Take off the trim ring that goes around the planetary. You can use a flathead screwdriver and a hammer to tap it off carefully, but be careful to avoid damaging the trim ring or the mixer. Then pull it off the mixer.
5. Remove the groove pin that holds the planetary to the center shaft. You can use a punch and carefully tap it out gently. Once the groove pin is out, set it aside.
6. Find the tabs where the screws are and use a flat-head screwdriver to pry the planetary down. Start on one side, then move to the other, working both sides until the planetary drops off. Then pull it straight down and remove it from the center shaft.
7. Take off the center shaft o-ring. Use a small flat-head screwdriver to pop it out of the groove and pull it off the shaft. Once it’s removed from the shaft, pull it off the mixer.

Step 2: Install the new center shaft o-ring

1. Carefully start inserting the new o-ring on the center shaft and push it up until it fits into its groove.
2. Put the planetary assembly back on. Line up the hole for the groove pin with the shaft and lift it. If the gears inside the mixer are misaligned, spin the shaft to align them.
3. If necessary, use a small Phillips screwdriver to adjust the shaft. Look through the opening and pull it down until the hole is aligned and open.
4. Use a punch to hold the hole open and insert the groove pin. Align the groove pin and tap it in with a hammer until it’s flush.
5. Put the trim ring back on. Lift it and make sure it’s level. If one side is higher than the other, adjust it until it’s correctly aligned. Then carefully tap the trim ring on with a rubber mallet until it’s in place.
6. Put the bowl back on by lining up the pin holes and setting it down. Lock it into place.
7. Attach the beater by lining up the shaft with the opening. Make sure the locking pin goes into the slot. Then lift the beater into place and lock it on.
8. Plug the mixer back in and test it to make sure everything is working correctly.

Read more: How To Clean And Maintain Your Stand Mixer

Additional information

Thanks for reading! We hope this guide helped you replace the center shaft o-ring on your KitchenAid stand mixer.
