How to replace electric stove drip pans

Underneath the coil burners of an electric stove are drip pans that help catch any spills or boilovers from pots and pans. Over time, these drip pans can become stained, rusted, or warped from constant heat exposure. In those cases, you’ll need to replace them with new ones.

Find replacement drip pans by entering your model number at AppliancePartsPros.com. Most orders arrive in just two business days.

Let’s walk through the simple process of removing the old drip pans and installing new ones to refresh your electric stove. With just a few tools and supplies, it’s a project you can tackle in about 10-15 minutes.

Read more: Electric Range Heating Coil Cleaning & Upkeep – AppliancePartsPros Blog

Disclaimer: The part replacement information provided in this article is based on general service manuals and may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What you need

• Replacement drip pans – Check your cooktop’s model number for your cooktop to find compatible replacement parts. If they are unavailable, universal drip pan sizes are 6 inches for small burners and 8 inches for large burners. Stainless steel or enamel-coated pans are good durable options.
• Screwdriver – You might need both a Phillips and flathead screwdriver to remove screws securing the drip pans or elements.
• Gloves – Wearing gloves helps protect your hands from sharp edges.
• Paper towels or rags – Useful for cleaning up any spills or messes under the cooktop.
• Small container – Keep an empty container near the cooktop so you can set aside small pieces like burners, screws, and drip pans and keep them together.

Read more: https://www.appliancepartspros.com/b/range-burner-receptacle-replacement-a-step-by-step-guide/

Safety precautions

• Turn off and unplug the stove or switch off the circuit breaker before starting any repair. to prevent electric shock.
• Allow the stove to completely cool off before handling any parts.
• Clean up any grease or food residue with a rag before lifting old drip pans.
• Wear gloves to protect your hands and fingers when removing metal parts.
• Keep children and pets away from the work area to avoid accidents or injury.
• Align all electric coils and elements correctly during the replacement process.

Replacement steps

1. Unplug the stove and turn off the circuit breaker connected to it.
2. Remove all the electric coil burners. Coil elements can usually be lifted directly up and off the cooktop. If they have retaining screws or clips holding them in place, use a screwdriver to loosen them first before you lift them off the top.
3. Set the elements aside on a protected surface. Be very careful when handling the elements to prevent cracking or shattering.
4. Use a screwdriver to unscrew any brackets or screws that are securing the drip pans to the cooktop base. These are usually located at the corners or along the edges. Set the screws aside in a safe place for reinstallation later.
5. Slowly and carefully lift out the old drip pans. Watch out for any leaks, drips or leftover grease residue as you remove them.
6. Place the old drip pans on top of the newspaper or drop cloth to contain any spills or stains.
7. Look at the stove surface under the pans. If it’s dirty, use a baking soda paste scrub and soft cloth to gently clean off any baked-on grime or food stains. The cooktop should lift up so you can easily clean under it. Rinse with a damp sponge and dry completely.
8. If the stove surface is clean, take the new replacement drip pan and position it exactly where the old pan was located. Double-check that the pan fully covers the burner area underneath.
9. Reinsert any screws or brackets to fasten the new drip pan into the same position as the old one. Use the screwdriver to tighten the screws, but be careful not to overtighten.
10. Put the burner elements back into their sockets by pushing the terminal ends gently into the receptacles. Make sure they’re aligned correctly.
11. Test the stove by plugging it back in and turning on the power. Make sure the burners heat up normally by turning them on briefly.

And that’s it! Be sure to check the drip pans periodically and repeat the replacement process as needed.
