How to replace Frigidaire oven bottom 316400603

Is your Frigidaire oven failing to bake your favorite dishes evenly, leaving you frustrated with hot and cold spots? The culprit might be a warped or cracked oven bottom, but don’t worry—replacing it is simpler than you think! Our comprehensive guide, complete with a step-by-step how-to video, will walk you through the entire process, transforming you into a confident DIY repair master in no time.

The oven bottom in your Frigidaire range serves as the floor of the oven cavity and allows heat to circulate evenly while baking. Over time and usually with very heavy use, the bottom of the oven may become warped or cracked.

Fortunately, replacing an old oven bottom is a straightforward DIY project most homeowners can handle. But you don’t have to complete this repair on your own! We’re here to help during every step in the process.

You can find a replacement oven bottom here. If you need other replacement parts for your Frigidaire range, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.

WATCH: How to install oven bottom

The purpose of an oven bottom & why it would need to be replaced

The oven bottom has two important jobs. First, it helps your food cook evenly by directing heat from the bake burner and spreading warmth with its flat surface. But if it’s warped, you might end up with spots that are too hot or too cold, and that’s no good for your dishes.

But that’s not all! The oven bottom also collects accidental spills and splatters. Just think about all those times when a bubbling casserole overflowed or melted cheese dripped everywhere. Without the oven bottom, those messes would find their way into hard-to-reach nooks and crannies of the range. You can think of the oven bottom like a protective shield for your range’s insides.

READ MORE: 7 Space-Saving Tips For Small Kitchens

What you need

• Oven bottom part number 316400603 (make sure it’s compatible with your specific range model BEFORE installing)
• Flathead screwdriver
• Towel
• Safety goggles (optional)

READ MORE: Pantry Organization: A Step-by-Step Guide

Keep safety first

Your safety should always be the top priority when performing any appliance repair.

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by preventing any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• If you have a gas range, shut off the gas supply to prevent any leaks while you work.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can clearly see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.

READ MORE: 4 Simple Ways to Reduce Kitchen Waste

How to replace the oven bottom

Step 1 – Remove the oven racks

1. Make sure the oven is turned off and unplugged from the power supply.
2. Grab hold of the rack and slide it forward until it stops, then lift it to remove it from the oven cavity. Put it aside on a countertop or table lined with a towel.
3. Remove the second rack the same as the first.

Step 2 – Remove the old oven bottom

1. Use the flat-blade screwdriver to remove the 2 screws at the back of the oven bottom.
2. Lift the back of the old oven bottom and slide it out of the oven cavity.

READ MORE: Reduce Your Energy Bill with These 6 Easy Home Tasks

Step 3 – Install the new oven bottom

1. Place the front edge of the new oven bottom under the lip on the front of the oven cavity.
2. Secure the bottom with the 2 screws.
3. Reinstall the oven racks.
4. Restore power to the range. If you have a gas range, remember to turn the gas supply back on.

READ MORE: How to prevent appliance fire hazards

FAQs

Q: How can I extend the life of my oven bottom?

A: Keep your oven clean and avoid using harsh chemicals or abrasive cleaners on the oven’s bottom. Refrain from placing foil at the oven’s base to trap food spills and grease, as this can cause damage like scratching and chipping on the surface over time.

Q: How should I clean my gas stove/range burners?

A: Remove the grates and burner caps, soak them in soapy water, and clean the surface with a non-abrasive scrubber. You can carefully use a pin or needle to clear any blockages in the burner’s holes.

Q: What’s the best way to clean an electric stove/range coils?

A: Make sure the stove is off, unplugged and cooled down. As you wipe the coils with a damp cloth and mild detergent, be careful to avoid water contact with the electrical connections. Dry the coils thoroughly before using the stove.

Q: How can I improve the energy efficiency of my stove or oven?

A: You can use lids on pots to reduce cooking time and select the correct burner size for your pot. Try to avoid opening the oven door frequently so the oven can maintain a consistent temperature.

READ MORE: 5 Common Mistakes That Shorten The Lifespan Of Appliances

More information

Thanks for stopping by! We hope this guide helped you replace your oven bottom.

If you run into any issues, just give us a call at 1-877-477-7278 or start a chat with a pro on our website so we can help you through it. We’ve got many more troubleshooting and repair guides on our DIY blog and YouTube channel, and, of course, all the parts you need to do it yourself at AppliancePartsPros.com. We can also help you troubleshoot common range and oven problems here.
