How to replace lint screen housing seal WE1M825 on a GE dryer

Is your GE dryer not drying as efficiently as it used to? A worn-out lint screen housing seal might be letting air escape, extending your drying times. Don’t worry—our step-by-step guide, complete with a how-to video just below, is here to help you replace it effortlessly and get your dryer back in tip-top shape.

Looking for the right part? Enter your appliance model number below to find the exact match and get your appliance running like new again!

On a GE dryer, the lint screen housing seal provides an airtight seal around the trap duct in your dryer. Over time, this seal can deteriorate, allowing air to enter the duct from the dryer’s cabinet, causing longer drying times. Fortunately, replacing it is a quick and easy repair that you can do yourself. With just a few basic tools and a little bit of time, you’ll have your dryer running again in no time. So let’s get started!

Watch here: How To: GE Lint Screen Housing Seal WE1M825

You can find a replacement lint screen housing seal WE1M825 here. If you need other replacement parts for your GE dryer, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.

Tools needed

• Phillips screwdriver
• 1/4″ nut driver
• Needle nose pliers
• Flathead screwdriver
• Part number WE1M825 (make sure it’s compatible with your model)

The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before attempting any maintenance or replacement work. This keeps you safe by preventing any risk of injury from electric shock.
• Shut off the gas supply to prevent any gas leaks while you work.
• Turn off the water supply at the outlet before beginning repairs to any appliance parts that hold water. Have towels ready for any residual water in the system when removing parts.
• Wear insulated work gloves to protect your hands from sharp metal parts, pinching hazards and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access the interior parts.
• Clear your workspace of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with bare wet hands. Make sure the work area is completely dry.
• Check your user manual to see if there are specific installation or safety instructions for your part or appliance.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause injury.
• Wear safety glasses when working with chemicals, dust or cleaning large debris to prevent injury.
• If the appliance has recently been used, give it plenty of time for any heating parts to cool down before working on it.

Replacement steps

The information in this article may not apply to your specific appliance model. We recommend consulting your manufacturer’s documentation or contact us with any questions.

Step 1: Remove the control panel

1. Remove the three top phillips screws located at the back of the control panel.
2. Slide the control panel to the left to disengage the bottom locking tabs.
3. Leave the control panel loose.

Step 2: Remove the top panel

1. Open the dryer door and remove the two phillips screws on each side of the door.
2. Close the door.
3. Lift the top panel of the dryer and pull it out.
4. Be cautious not to damage any wires or connections.

Step 3: Remove the front panel

1. Use the quarter-inch nut driver to remove the two top screws on each side of the front panel.
2. Tilt the front panel towards you and lift it off the bottom clips.
3. Take care not to damage any wires connected to the front panel.
4. Bend the cover tab and move the switch cover out of the way.
5. Use needle-nose pliers to carefully pull apart the wiring harness connector plug.
6. This will disconnect the wires from the terminals of the door switch.
7. Place the front panel aside against the dryer.

Step 4: Replace the lint screen housing seal

1. Unscrew the light bulb located inside the dryer.
2. Use a flathead screwdriver to release and remove the top support bearing.
3. Pop out the bottom support and duct assembly from the front panel.
4. Take the duct assembly to a clean work surface.
5. Remove the old lint screen housing seal from the assembly.
6. Clean the surface of the assembly so it is free from any debris.
7. Peel off the adhesive protective strip on the new lint screen housing seal.
8. Install the new lint screen housing seal onto the duct assembly, aligning it properly.

Step 5: Reassemble the dryer

1. Place the lint trap duct assembly onto the front panel, starting with the left side first.
2. Make sure the edge of the assembly is over the lip of the door and snap it into place.
3. Lock the switch cover back into position.
4. Install the upper support bearing securely.
5. Screw in the light bulb to its original location.
6. Place the front panel on the left side of the dryer.
7. Reconnect the wires to the terminals of the door switch.
8. Place the switch cover back into position with the tab locked.

Step 6: Secure the front panel and top panel

1. Align the bottom slots of the front panel with the tabs on the dryer cabinet.
2. Insert the side tabs into the cutouts on the cabinet and lift the drum at the same time.
3. Secure the front panel with the two quarter-inch screws.
4. Align the tabs on the top panel with the slots on the cabinet frame.
5. Slide the top panel into place.
6. Open the dryer door and secure the top panel with the two phillips screws.
7. Close the door.

Step 7: Reinstall the control panel

1. Slide the control panel to the right to lock the bottom tabs.
2. Secure the control panel with the three phillips screws.

Step 8: Test the dryer

1. Plug the dryer back in and turn it on.
2. Check if the dryer is drying properly.

Additional information

Thanks for reading! We hope this guide helped you replace the lint screen housing seal on your GE dryer.
