How to replace Samsung dishwasher leak detector sensor DD94-01062A

The leak detector sensor on a Samsung dishwasher does what its name suggests: it detects the presence of water leaks and communicates with the control board if one is found. But if the leak detector is faulty, your dishwasher may signal a leak when there’s really not one, or be prevented from catching an active leak.

You might need to replace the leak detector sensor if you’re seeing frequent error codes related to water leakage, persistent water pooling or dripping underneath the dishwasher or dealing with an overall malfunctioning or non-responsive leak detection system.

You can find a replacement leak detector sensor DD94-01062A here. If you need other replacement parts for your Samsung dishwasher, just enter your model number at AppliancePartsPros.com to find them. It’s that easy! Most orders arrive in just two business days, and we have thousands of guides to show you how to install your new parts.

Disclaimer: The part replacement information provided in this article may not apply to your specific appliance model. While we strive to offer helpful advice for DIY appliance repairs, variations in models and configurations can lead to differences in troubleshooting steps, error codes and part replacements. For the most accurate guidance, we strongly recommend consulting the technical sheet for your specific appliance model.

What you need

• Replacement leak detector sensor (make sure it’s compatible with your specific dishwasher model before installing)
• Phillips screwdriver
• Flathead screwdriver
• 5/8-inch wrench
• 9/64-inch hex screwdriver
• Pliers
• Towels

Disclaimer: The specific tools required may vary depending on the model of your appliance and the type of fasteners used on it. Always consult the user manual or refer to any specific instructions provided by the manufacturer for the recommended tools for your appliance model.

Read more:  How to Troubleshoot a Dishwasher Door that Opens Too Fast

Safety precautions

When working on any appliance, remember to keep safety first. Here are some tips to keep in mind:

• Always power off and unplug your appliance or switch off the circuit breaker before you attempt any maintenance or replacement work. This keeps you safe by eliminating any risk of electric shock.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Turn off the water supply at the outlet before beginning repairs. Keep towels ready to catch any residual water in the system when removing parts.
• Take your time while working to prevent accidents and personal injuries. Rushing is the enemy of precision.
• Work in a well-lit area so you can see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Always take photos or make a note of wiring terminals or other connections before disconnecting them to make reassembly easier.

Read more: Dishwasher Not Fully Cleaning Dishes: Top 5 Reasons & Fixes

How to replace the leak detector sensor

Follow these steps to swap out the leak detector sensor in your Samsung dishwasher.

1. Unplug your dishwasher from the power outlet.
2. Find the water supply valve for the dishwasher and shut it off.
3. Use a Phillips-head screwdriver to remove the screws holding the lower access panel at the front of the dishwasher. Carefully remove the lower access panel.
4. Lay some towels under the water supply line and inlet valve.
5. Use a 5/8-inch wrench to unthread the water supply line from the inlet valve on the dishwasher. Be prepared for some water to spill out.
6. Find the junction box cover on the side or back of the dishwasher.
7. Use a screwdriver to unthread the screw securing the junction box cover, then remove it.
8. Note the location of the wires connected to the dishwasher. Take a photo to help with reassembly later on.
9. Untwist the wire nuts to disconnect the wires.
10. Unthread the strain relief nut and detach the strain relief from the junction box.
11. Find the drain hose that’s connected to the sink drain or garbage disposal. Disconnect the drain hose and feed it through the cabinet.
12. Take a minute to check the drain hose for any blockages or damage. Clean it or replace it as needed.
13. Open the dishwasher door and find the mounting bracket screws on the top of the dishwasher. Use a screwdriver to unthread the screws.
14. If needed, adjust the legs of the dishwasher to lower it. To lower the rear leveling leg, use a 9/64-inch hex head screwdriver to rotate the adjustment rod at the front of the dishwasher clockwise.
15. Carefully pull the dishwasher away from the cabinet to avoid damaging any connections or surroundings.
16. Tip the dishwasher back so it rests on its rear panel.
17. Use a Phillips-head screwdriver to unthread the screws holding the bottom access panel. Pull the panel forward to access the leak detector sensor.
18. Disconnect the wire connector from the old leak detector sensor.
19. Unthread the screws securing the old leak sensor to the access panel, then remove the old sensor.
20. Align the new leak sensor on the access panel and attach it with the screws.
21. Connect the wire connector to the new leak detector sensor.
22. Reposition the access panel on the base of the dishwasher and snap the retaining tabs into place.
23. Use the screws to secure the access panel.
24. Gently slide the dishwasher back into the cabinet, and as you do, avoid pinching any cables or hoses.
25. Adjust the machine’s leveling legs if needed to make sure the dishwasher is level.
26. Secure the dishwasher to the cabinet or countertop by replacing and tightening the mounting bracket screws.
27. Feed the drain hose through the cabinet and reconnect it to the sink drain or garbage disposal. Make sure the hose is elevated above the connection point.
28. Fully position the wire strain relief in the junction box and secure it with the strain relief nut.
29. Reconnect the wires with the wire nuts and make sure the wire connections are aligned.
30. Align the junction box cover and secure it with the screw.
31. Reconnect the water supply line to the inlet valve on the dishwasher.
32. Replace the lower access panel and secure it with the screws.
33. Turn on the water supply to the dishwasher.
34. Plug the dishwasher back into the power outlet.
35. Run a test cycle to make sure the new leak detector sensor is working correctly. Check for any leaks or other issues.

Read more: How to Replace a Dishwasher Drain Hose

Additional information

Thanks for reading! We hope this guide helped you replace the leak detector sensor on your Samsung dishwasher.
