How to replace Samsung refrigerator upper hinge cam riser DA66-00558B

Is your refrigerator door refusing to close, letting cold air and frustration leak into your kitchen? Don’t worry; the solution could be as simple as replacing a small yet essential part called the upper hinge cam riser. Watch our step-by-step how-to video below and learn how you can easily fix this common issue yourself with just a few tools!

There’s something oddly unsettling about a refrigerator door that won’t close properly – it’s like a book with a bent cover, never quite fitting right. If your Samsung refrigerator has been leaving you with a slight gap of cold air and frustration, the culprit might just be a weary upper hinge cam riser. This small but mighty component helps your fridge door close and seal correctly, keeping the cold in and your worries out.

Here’s the good news: fixing a disobedient fridge door isn’t as daunting as it sounds. Replacing a worn-out or broken upper hinge cam riser is an easy DIY repair that you can knock out in just a few minutes with just a few tools.

If you need a replacement upper hinge cam riser, you can order part DA66-00558B here. You can also use your model number to search AppliancePartsPros.com for more Samsung fridge parts.

Watch the full repair here!

What you need

• Phillips screwdriver
• 3/8″ open-ended wrench
• 10mm socket wrench
• Samsung upper hinge cam riser

What is the upper hinge cam riser?

The upper hinge cam riser is a small plastic part located at the bottom of the freezer door, right above the door hinge. Its job is to control the opening and closing motion of the freezer door so it can close tightly and provide a good seal.

Over time, the upper hinge cam riser can wear out or break. If the cam riser is damaged, the freezer door will fail to seal completely when closed, and cold air can escape from the freezer. Warm air can also seep in, which could cause ice to build up and food to spoil.

Read more: Refrigerator Door Won’t Open or Close: Top 5 Reasons and Fixes

Keep safety first

Anytime you repair an appliance, safety should always come first. Follow these precautions when working on your Samsung refrigerator:

• Always power off and unplug your appliance or switch off the circuit breaker before attempting any maintenance or replacement work. This keeps you safe by preventing any risk of electric shock.
• Turn off the water supply to prevent leaks and water damage.
• Be careful when handling the fridge doors. The doors are heavy and awkward to maneuver, so grab a sturdy stool, ladder or extra person to help if needed.
• If the appliance has recently been used, give it plenty of time to cool down before working on it.
• Take your time and don’t rush while working to prevent accidents and personal injuries.
• Work in a well-lit area so you can clearly see and access appliance parts.
• Keep your workspace free of clutter and other obstacles. Keep children and pets away from the work area.
• Never work on internal parts with wet hands. Make sure the work area is completely dry.
• Check the user manual to see if there are specific installation or safety instructions related to your appliance or replacement part.
• Be gentle when handling or removing parts. Excessive force might damage the appliance or cause personal injury.
• Wear insulated work gloves to protect your hands from sharp metal parts and debris.
• When working with wires, avoid touching any exposed wires or terminals. If you need to touch a wire, use a non-conductive tool or wear insulating gloves to prevent electrical shock.
• Don’t test live voltage with a multimeter if you’re unfamiliar with how to prevent short-circuiting.
• Consider wearing safety glasses and/or a dust mask when working with chemicals, dust or a large amount of debris to prevent irritation or injury.

Read more: How to Level a Refrigerator in 6 Easy Steps

Replacement instructions

Step 1: Remove the toe grill

The toe grill is the ventilated cover at the bottom front of the refrigerator. Removing this provides access to the water lines and lower hinge.

1. Turn off the fridge and disconnect it from the power source.
2. Make sure the fridge water supply is disconnected. Find the shut-off valve for the fridge’s water line so you can turn off the water.
3. Use a Phillips screwdriver to remove the three screws securing the toe grill.
4. Set the toe grill aside.

Step 2: Disconnect the water lines

1. Find the two water lines running from the bottom hinge into the refrigerator cabinet. You’ll need to disconnect them to detach the freezer door.
2. Use a 3/8″ open-ended wrench to loosen the compression fittings on both water lines. This will release the lines from the connector stems.
3. Have a towel ready to catch any water remaining in the lines.
4. Detach both water lines from the connector stems.

Step 3: Remove the top hinge cover

With the doors closed, move to the top of the refrigerator.

1. Remove the two Phillips screws securing the plastic hinge cover.
2. Lift off the cover.
3. Be careful not to stress the wiring harness when removing the cover.

Step 4: Disconnect the wiring harness

The wiring harness has two plugs that connect to the electronics in the hinge cover.

1. Press the release tabs on both plugs to disconnect them.
2. Remove the single Phillips screw that’s holding the green ground wire to the hinge.

Step 5: Detach the top hinge

1. Use a 10mm socket wrench to remove the three 10mm bolts securing the top hinge.
2. Support the freezer door as you remove the last bolt.
3. Lift the top hinge straight up to detach it from the cabinet.
4. Rest the freezer door on top of the fresh food door.

Step 6: Remove the freezer door

1. Support the weight of the door as you lift it up off the bottom hinge pin.
2. Tilt the door slightly outward to make room for the water lines.
3. Gently pull the water lines out from the bottom hinge as you remove the door.
4. Gently set the door down on its side.

Read more: How To Deep Clean Your Refrigerator

Step 7: Replace the cam riser

The cam riser is secured by a single Phillips screw on the underside of the freezer door.

1. Remove the Phillips screw holding the old cam riser and slide the riser off the mounting plate.
2. Slide the new cam riser into position over the water lines.
3. Insert and tighten the Phillips screw to secure the new part.

Step 8: Reinstall the freezer door

1. Lift the freezer door and gently fit the water lines into the slots on the bottom hinge.
2. Lower the door onto the hinge pin.
3. Open the door enough to access the top.
4. Lift the door into place and align it with the screw holes.

Step 9: Replace the top hinge

1. Hold the top hinge in place over the aligned screw holes.
2. Insert the two outer 10mm bolts and tighten them.
3. Align the door and insert the center bolt before tightening all three bolts securely with the socket wrench.

Step 10: Reconnect the wires and cover

1. Reattach the two wiring harness plugs to the connectors in the hinge cover.
2. Replace the ground screw.
3. Set the hinge cover in place over the wiring.
4. Insert and tighten the two Phillips screws.

Step 11: Reconnect the water lines

1. Press the water lines firmly back into their connector stems at the base of the refrigerator.
2. Check that the lines are fully seated.

Step 12: Replace the toe grill

Align the toe grill and secure it with the three Phillips screws you removed earlier.

Read more: A Complete Guide to Refrigerator Organization

Wrap up

Once the repair is complete:

1. Plug the refrigerator back in and restore the power and water supply.
2. Let the fridge chill for a few hours.
3. Monitor the doors and check for leaks over the next 24 hours.
